UBI EasyCoder 501 Ticketing – User's Manual
PAPER LOAD
Internal Supply
The EasyCoder 501 Ticketing can use an internal paper roll
with a maximum diameter of 152 mm (6").
1
Turn the printhead lift knob to "Load" position.
2
Fit a new paper roll on the paper supply spool and push the
roll inwards as far as it will go.
3
Thread the paper underneath the guide shaft and under the
guide plate of the label stop sensor.
4
Thread the paper past the print roller.
5
Adjust the green guide ring so the paper is guided with a
minimum of play.
6
Turn the printhead lift knob to "Print" position.
7
Feed out at least one ticket by pressing the < Feed > key.
To tear off the paper, pull it downwards.
