VTech VM341 Quick Start Manual

Mount the baby monitor - Method 2
If you drill the holes into a stud, go to
Check for reception strength and
NOTE
camera angle before drilling the
step 3.
holes.
-OR-
Place the wall mount on a wall and
If you drill the holes into an object other
then use a pencil to mark the top
than a stud, insert the wall anchors into
and the bottom holes as shown.
Remove the wall mount and drill
the holes. Tap gently on the ends with a
two holes in the wall (7/32" drill bit).
hammer until the wall anchors are flush
with the wall.
1
2
3
Insert the screws into the holes Place the baby unit on the wall mount.
and tighten the screws until Tighten the screw into the threaded
only 1/4 inch of the screws are socket at the bottom to secure the baby
exposed. unit. Align the holes on the wall mount
with the screws on the wall, and slide the
wall mount down until it locks into place.
Sound activation
Night vision
The baby unit has infrared LEDs that
allow you to see your baby at night or
in a dark room. When the baby unit
detects low light levels, the infrared
LEDs turn on automatically.
When the infrared LEDs are on, the
NOTE
image is in black and white. This is
normal due to external light sources.
Depending on the surroundings
TIP
and other interfering factors, like
lightings, objects, colors and
backgrounds, the display resolution
may vary. Adjust the baby unit's
angle, or place the baby unit at a
higher level to prevent glare and
blurry display.
Specifications are subject to change without notice.
© 2015 VTech Communications, Inc.
All rights reserved. 03/15. VM341-X_QSG_V1.0
Document order number: 96-010233-010-100
Go to www.vtechphones.com
to register your product for
enhanced warranty support
SOUND-ACTIVATED SCREEN
and latest VTech product news.
On
O
VM341
VM341-2
VM304

Quick start guide
