Section Five - Result Codes

OK
RING
ERROR
NO DIALTONE
NO ANSWER
CONNECT 2400 EC*
CONNECT 9600 EC*
CONNECT 12000 EC*
CONNECT 16800 EC*
CONNECT 31200 EC*
CONNECT 24000 EC*
CONNECT 28800 EC*
CONNECT 32000 EC*
CONNECT 34000 EC*
CONNECT 38400 EC*
CONNECT 40000 EC*
CONNECT 44000 EC*
CONNECT 48000 EC*
CONNECT 52000 EC*
CONNECT 56000 EC*
CONNECT 58000 EC*
CONNECT 115200 EC*
* EC denotes one of the following extensions depending on the
error control method used when extended result codes are
enabled.
V42bis - V.42 error correction and B.42bis data compression
V42 - V.42 error correction only
MNP 5 - MNP Class 4 error correction and MNP Class 5 data
compression
MNP 4 - MNP Class 4 error correction only
NoEC - Error correction is off

Section Six - Troubleshooting

This section describes some of the common
problems you may encounter while using your modem.
If you can not resolve your difficulty after reading this
chapter, contact your dealer or vendor for assistance.
Modem does not respond to commands.
