High Performance K56Plus/V.34+/V.42bis 56K BPS Plug & Play Internal Voice/FAX/Data/SVD Modem With Advanced Speakerphone functions User's Manual Contents Section One - Introduction ... 1 Section Two - Installation ... 1 Section Three - AT Command Set ... 7 Section Four - S Registers ... 14 Section Five - Result Codes ... - Page 2 The information contained in this manual has been validated at the time of this manual's production. The manufacturer reserves the right to make any changes and improvements in the product de- scribed in this manual at any time and without notice.
-
Page 3: Section One - Introduction
Section One - Introduction This 56 Kbps* Plug and Play FAX/Voice/Data/ SVD Speakerphone Modem connects your computer to all popular high speed modems available today. The modem incorporates “K56Plus” (56Kbps) technology to provide increased download speeds using regular telephone lines. The modem incorporates Plug and Play for ease of installation. - Page 4 (e.g., Windows 95), B) A Plug and Play Revision 1.0a compliant PC. Proceed to Section 2.3 now if you have every- thing required. If you have neither 2A or 2B above, youneed to install Windows 95 to provide Plug and Play function- ality to your PC.
- Page 5 7. Connect the telephone cable from the modem's LINE connector to the telephone wall jack. 8. Optionally, connect your telephone to the modem's PHONE connector. 9. Turn your computer on. Your modem is now installed. 2.4 Hardware Configuration (Plug and Play) Your modem is configured using the Plug and Play (PnP) capabilities of your computer.
- Page 6 2.4.1.1 Windows 95 Release 4.00.950 When Windows 95 starts for the first time after card installation, it detects the modem and displays the New Hardware Found dialog box. Under New Hardware Found, when asked to “Select which driver you want to install for your new hardware,”...
- Page 7 2.4.2 Configuring in a Plug and Play System with- out Windows 95 When this modem is installed in a Plug and Play system without Windows 95, the computer's BIOS will assign a COM port and IRQ line to the modem. Proceed to Section 2.5, Software Installation/ Configuration.
- Page 8 RJ-11 jack marked “PHONE” or by attaching a micro- phone to the MIC jack and a speaker to the SPK jack of your sound card. Follow instructions in the FAX/ Voice/Speakerphone software on recording and play- back of voice prompts. 2.7 Testing Your Modem After Installation In order to test your modem you should be familiar with your communication software.
-
Page 9: Section Three - At Command Set
are interested in accessing the modem manually, and not through the included software. Section 4 and 5 contain reference material, and can be skipped. If you have difficulties getting your modem to work, read Section 6 - Troubleshooting to find answers to com- monly asked questions and problems. - Page 10 DS=n Bell mode V.23 originate mode @ 75 bps transmit/ 1200 bps receive V.23 originate mode @ 1200 bps transmit/75 bps receive Selects V.21 at 300 bps Selects Bell 103 at 300 bps 0 - 9, A-D, # and * last number redial pulse dialing touch-tone dialing...
-
Page 11: Extended At Commands
Sr=n 3.4 Extended AT Commands &C_ &C0 &C1 &D_ &D0 &D1 Return to Data Mode Return to Data Mode and initiate an equalizer retrain Set Pulse dial as default Modem sends responses Modem does not send responses Read and display value in register r. Set register r to value n (n = 0-255). - Page 12 &D2 &D3 &F_ &F &G_ &G0 &G1 &G2 &K_ &K0 &K3 &K4 &L_ &L0 &M_ &M0 Asynchronous operation &S_ &S0 &S1 &T_ &T0 &T1 &T3 &T6 &V &V0 &W_ &W0 Stores the active profile as Profile 0 &W1 Stores the active profile as Profile 1 &Y_ &Y0 &Z n =x...
- Page 13 %C1 Enable MNP Class 5 data compression &Q_ &Q0 &Q5 V.42 data link with fallback options &Q6 Send a 1/10 second line break to the modem, where n = 1 to 9. At normal connect, the default is 3 Set break control, where n= 0 to 5. The effect of this command depends on the modem’s operating condition.
-
Page 14: Fax Class 1 Commands
3.6 Fax Class 1 Commands +FCLASS? +FCLASS=? +FCLASS=n +FMI=? +FMM=? +FMR=? +FRH=n +FRH=? +FRM=n +FRM=? +FRS=n +FTH=n +FTH=? +FTM=n +FTM=? +FTS=n 3.7 Fax Class 2 Commands +FAA=n +FAXERR +FBOR +FBUF? +FCFR +FCLASS= +FCON +FCIG +FCIG: +FCR +FCR= +FCSI: +FDCC= +FDCS: +FDCS= +FDIS: +FDIS=... - Page 15 +FDTC: +FET: +FET=n +FHNG +FLID= +FLPL +FMDL? +FMFR? +FPHCTO +FPOLL +FPTS: +FPTS= +FREV? +FSPL +FTSI: 3.8 SVD Commands -SAC -SCD= -SDA -SDT -SEM -SER? -SFA -SFX -SIC -SIP -SMD -SMS=X,Y,Z,T Select ASVD/DSVD Mode. The X -SMT -SNO -SOR -SQQ -SQR=n -SQS=X,Y Report the polled station capabilities Post Page Message Response...
-
Page 16: Section Four - S Registers
-SRM -SSE=n n=0 -SSP -SSR -SSV -STM -STT -SVV Section Four - S Registers Your modem has 28 registers, designated S0 through S92. Table 4-1 shows the registers, their functions, and their default values. Some registers can have their values changed by commands. If you use a command to change a register value, the command remains in effect until you turn off or reset your modem. -
Page 17: Section Five - Result Codes
Connection speed 56K dial line rate S42-43 Reserved LAPM negotiation Sleep mode timer Local phone status Transmit level Section Five - Result Codes RING ERROR NO DIALTONE NO ANSWER CONNECT 2400 EC* CONNECT 9600 EC* CONNECT 12000 EC* CONNECT 16800 EC* CONNECT 31200 EC* CONNECT 24000 EC* CONNECT 28800 EC*... -
Page 18: Section Seven - Support And Service
o t h e m o d e m o n t h e c o r r e c t C O M p o r t a n d I R Q s e t t i n g ( s a m e C O M p o r t a n d I R Q s e t t i n g a s t h e m o d e m ) . Y o u r c o m m u n i c a t i o n s o f t w a r e m u s t k n o w w h i c h a d d r e s s y o u r m o d e m i s u s i n g i n t o “... -
Page 19: Appendix B - Notices
C O M p o r t IRQ lines: FAX Group: FAX Command set: Transmit level: Receiver Sensitivity: -39 dBm (V.34); -43 dBm (all UART: Data format: Power: T e m p e r a t u r e : Caller ID: PnP: Speakerphone:... -
Page 20: Doc Compliance Information
T h e F C C a l s o r e q u i r e s t h e t r a n s m i t t e r o f a F A X t r a n s m i s s i o n b e p r o p e r l y i d e n t i f i e d ( p e r F C C R u l e s P a r t 6 8 , S e c . 6 8 . 3 8 1 ( c ) ( 3 ) ) . S t a t e m e n t F C C C l a s s B T h i s e q u i p m e n t h a s b e e n t e s t e d a n d f o u n d t o c o m p l y w i t h t h e l i m i t s f o r... - Page 21 N O T I C E : T h e L o a d N u m b e r ( L N ) a s s i g n e d t o e a c h t e r m i n a l d e v i c e d e n o t e s t h e p e r c e n t a g e o f t h e t o t a l l o a d t o b e c o n n e c t e d t o a t e l e p h o n e l o o p w h i c h i s u s e d b y t h e d e v i c e , t o p r e v e n t o v e r l o a d i n g .
