Summary of Contents for Viking Range RVEWD
- Page 1 Installation 3 Series Built-In Electric Warming Drawer...
-
Page 2: Table Of Contents
Table of Contents Warnings & Important Safety Instructions _______________________________________________3 Dimensions _________________________________________________________________________4 Specifications _______________________________________________________________________5 Cutout Dimensions __________________________________________________________________6 Electrical Requirements ______________________________________________________________7 General Information__________________________________________________________________8 Installation __________________________________________________________________________9 Final Preparation ___________________________________________________________________11 Performance Checklist ______________________________________________________________11 Service & Registration_______________________________________________________________12... - Page 3 IMPORTANT– Read and Follow! • Before beginning, please read these • The installer must leave these instructions instructions completely and carefully. with the consumer who should retain for local inspector’s use and for future reference. Your safety and the safety of others is very important.
-
Page 4: Dimensions
Dimensions ( 2 5 ” 8 - 3 1 / 3 ( 2 2 2 ” - 1 / ( 7 4 4 ” 2 ” - 1 / ( 5 9 ” - 7 / ( 6 9 27-7/16” (69.7 cm) 1-5/8”... -
Page 5: Specifications
(22.8 cm) (When facing cabinet, opening is 2” located on right side.) (5.1 cm) 2” (5.1 cm) Specifications Description RVEWD/CRVEWD Overall width 29-1/2” (74.9 cm) Overall height (from bottom) 10” (25.2 cm) Overall depth (from rear) To end of handle 27-7/16”... -
Page 6: Cutout Dimensions
Cutout Dimensions Indoor RVEWD/CRVEWD Cutout width (A) 28-1/4” (71.8 cm) Cutout depth (B) 23-1/2” (59.7 cm) Cutout height (C) 9-1/4” (23.5 cm) Flush Mount Option: Note: To install the warming drawer in a flush mount application, a flush mount accessory kit is required and sold separately. -
Page 7: Electrical Requirements
120V/15 amp minimum 2-wire HAZARD wtih ground circuit. Maximum amp usage. To avoid the risk of electrical shock, personal injury or death; RVEWD/CRVEWD verify electrical power is turned off at the Max. amp 450 watts breaker box until the range is installed usage 3.8 amps... -
Page 8: General Information
General Information READ AND FOLLOW ALL WARNING • When installing this unit directly below AND CAUTION INFORMATION other units, only install with Viking built- WHEN INSTALLING THIS in products. APPLIANCE. • Remove warming drawer carefully from Moving, Handling and Unpacking carton. -
Page 9: Installation
Installation Pull out warming drawer Slide finger along right and left side pan until fully extended. until you reach the black hand latches (located at the front of the rails). Pull up on both the right and left latches and pull out drawer pan support. Electrical opening (from rear) 2”... -
Page 10: Final Preparation
Installation (cont.) Slide cavity assembly into the cabinet opening. Secure the warming drawer using four #8 mounting screws (four screws provided). Replace drawer assembly. Final Preparation • All stainless steel body parts should be wiped with hot, soapy water and with a liquid cleaner designed for this material. -
Page 11: Service & Registration
Only authorized replacement parts may be used in performing service on the appliance. All servicing should be referred to a qualified technician. Contact Viking Range, LLC, 1-888-845-4641, for the nearest service parts distributor in your area or write to: VIKING RANGE, LLC... - Page 12 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-845-4641 or visit our website at vikingrange.com in the US or brigade.ca in Canada (070115) F21201A EN...
