- Page 1 Installation Guide Viking Range Corporation 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-845-4641 D30FTW - Warming Drawer Accessory Flush Mount Kit F20702B EN (020113)
- Page 2 Installing Flush Mount Trim Removing Existing Trim Remove the two existing side trim pieces from the warming drawer. There should be one trim After removing the existing side trim pieces, install the flush mount trim piece to the warming piece on each side of the drawer. drawer.
- Page 3 Securing Inside the Cutout Preparing the Cutout Side View In order for the unit to sit properly inside the cutout, the bottom must be built-up or “shimmed” by 1/2” blocking (See illustrations below). This will provide stability for the unit and allow it to sit upright when pushed back into the wall.
- Page 4 Securing Inside the Cutout (cont.) Top View Distance will vary depending on the cabinet Vertical Blocking Screw Screw CRITICAL DIMENSIONS A 28-1/2” (72.4 cm) 1-1/2” (3.8 cm)
