Caldera Outdoor Fire Bowl
FOR OUTDOOR USE ONLY

Tools needed for assembly:

CAUTION
Read and follow all safety statements, warnings,
assembly instructions and use & care directions
before attempting to assemble
Model • 04501128

Assembly Instructions

.
Cross head screwdriver
Adjustable spanner
(not supplied)
WARNING
Do not use this unit on a wood deck or on combustible
surfaces such as dry grass, leaves, mulch, etc. Do not
use this unit near heat sensitive or combustible
structures such as vinyl or wood siding.
04501128 / 42804023 (01-13-04)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 04501128 and is the answer not in the manual?

Questions and answers

Summary of Contents for Char-Broil 04501128

  • Page 1: Assembly Instructions

    Do not assembly instructions and use & care directions use this unit near heat sensitive or combustible before attempting to assemble structures such as vinyl or wood siding. 04501128 / 42804023 (01-13-04)
  • Page 2 HARDWARE Hardware is shown actual size. You may have spare hardware after assembly is complete. #10-24x3/8” #10-24 1/4-20 1/4-20x1/2” Combo Truss Head Keps Lock Nut Keps Lock Nut Machine Screw Carriage Bolt Ref. No. Description Qty. Bottom Ring Top Ring Fire Bowl Ash Catcher...
  • Page 3 Make sure legs (1) are on the inside of ring (2), attach legs to lower ring as shown using 4X B from the outside and 4X C on the inside. Tighten nuts after all four legs are attached. Repeat this step for areas 2, 3 and 4. Making sure the legs (1) are on the inside of ring, attach legs to upper ring (3) as shown using 4X B from the outside and 4X C on the inside.
  • Page 4 Using 3X A from inside the bowl (4) and 3X D attach ash catcher bracket (5) to the bottom side of bowl. Tighten all nuts. Assembly of Ash Catcher Lower bowl onto assembled base Completed view of Caldera Fire Bowl After Assembly...
  • Page 5 WARNINGS • This product is intended for OUTDOOR USE ONLY. • This product is NOT suitable for use on decking or other flammable surfaces such as dry grass, wood chips, leaves or decorative bark. • Ensure when positioning the unit it is sufficiently clear of flammable items or material such as fencing, wooden and plastic structures or similar.
  • Page 6 SERVICE Char-Broil International L.L.C. Bradley House Bircholt Road Parkwood, Maidstone, Kent, ME15 9XY Phone 01622 6774244 Fax 01622 688124 For Warranty and replacement parts support@charbroil.co.uk sales@charbroil.co.uk...
