Firebowl
Firebowl
with Screen
with Screen
For Outdoor
Use Only
CAUTION
THIS UNIT IS HEAVY!
DO NOT assemble without a helper.
CAUTION
Some parts may contain sharp edges – especially as
noted in manual. Wear protective gloves if necessary.
CAUTION
Read and follow all safety statements, warnings,
assembly instructions and use & care directions before
attempting to assemble.
WARNING
All surfaces can be hot during use. Use protection as
required to prevent burning.
WARNING
Do not use this unit on or near combustible surfaces or
structures such as wood decks, dry leaves or grass, vinyl
or wood siding, etc. SEE OWNER'S MANUAL FOR
IMPORTANT SAFETY INFORMATION.
WARNING
NEVER LEAVE FIRE UNATTENDED!
Do not allow small children near flame. Hot embers can
fly out in breezy conditions. Adequate fire extinguishing
material should be readily available.
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off carbon
monoxide, which has no odor. NEVER burn charcoal
inside homes, vehicles or tents.
06501328
04201101
06501328 • 42804201 • 12-04-07
Advertisement
Table of Contents
Related Manuals for Char-Broil 06501328
Summary of Contents for Char-Broil 06501328
- Page 1 Burning charcoal inside can kill you. It gives off carbon All surfaces can be hot during use. Use protection as monoxide, which has no odor. NEVER burn charcoal required to prevent burning. inside homes, vehicles or tents. 06501328 • 42804201 • 12-04-07...
- Page 2 STOP! Missing a part? Call Our Help Line No need to go back to the store! The store where you made your purchase 1-800-241-7548 does not stock parts for this item. If you need parts, whether they are missing or damaged, call the Customer Service toll free Help Line.
-
Page 3: Parts Diagram
PARTS DIAGRAM MODEL No. 06501328 PARTS LIST ITEM DESCRIPTION 29001275 FIREBOWL RING KIT 29001278 LEG KIT 29001089 FIREBOWL 55710180 ASH CATCHER KIT 10000179 LIFT BOLT F/ FIRE SCREEN 29100803 MESH FIRE SCREEN ASSEMBLY 42804201 ASSEMBLY INSTRUCTIONS 55710181 HARDWARE BAG HARDWARE LIST Hardware is shown actual size. -
Page 4: Product Assembly
PRODUCT ASSEMBLY Make sure leg is on the outside of the firebowl ring, attach each leg to support bar using two #10-24x1/2” screws from the outside and two #10-24 keps nuts on the inside. Do not fully tighten until all four legs are attached. Firebowl Ring Firebowl Ring Support Bar... - Page 5 Attach lift bolt to fire screen with one 1/4-20 keps nut. Lift Bolt Fire Screen Place firebowl into firebowl ring assembly, then place fire screen onto firebowl Fire Screen Firebowl Firebowl Ring...
-
Page 6: Use And Maintenance
If you notice any of these surface conditions before the outdoor fireplace is used, contact the Char-Broil Service Center for a replacement of the defective component. Manufacturing defects are covered under Char-Broil's 90 Day Limited Warranty. -
Page 7: Limited Warranty
Company. Thermos® is a registered trademark of the Thermos Company and its affiliates. Artisan Collectiion by Char-Broil™, C3 and Design™, Char-Broil and Design™, Flame Design™, FlavorTents™, Grill 2 Go™, Grillin’ Stick™, Keeper of the Flame™, Keepers of the Flame™, Natural Grip™, Outdoor Cooking Collection and Design™, Patio Bistro™, PrecisionFlame™, Pro-Check™, QuickSet Grills and Design™, SmokerTents™, The Big Easy™. - Page 8 Please register your product online at: www.grillregistration.com (If you register online, you do not need to send in this registration card.) PLEASE FILL OUT THIS CARD AND RETURN IT 10 DAYS OF PURCHASE. . FOR WARRANTY WITHIN FAILURE TO RETURN MAYAFFECT YOUR WARRANTY COVERAGE SERVICE PROOF OF PURCHASE WILL BE REQUIRED.
