Operating Instructions •
Some dust created by power sanding, sawing, grinding, drilling,
and other construction activities contains chemicals known to
cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement
and other masonry products, and
• arsenic and chromium from
chemically-treated lumber.
Your risk from these exposures varies, depending on how often
you do this type of work. To reduce your exposure to these
chemicals: work in a well ventilated area, and work with
approved safety equipment, such as those dust masks that are
specially designed to filter out microscopic particles.
Blows Per Minute ..................4,500
Bore ..................................11/16"
Stroke ................................1-5/8"
Air Inlet............................1/4 NPT
Hose Size ........................3/8" I.D.
SX235KTB
Warning Information • Parts Breakdown

SPECIFICATIONS

Air Pressure ........................90 PSI
Air Consumption..................4 CFM
Sound Level......................105 dBA
Length ................................5-1/2"
Shipping Wt.................3-9/16 lbs.
1
ALWAYS READ
INSTRUCTIONS
BEFORE USING
POWER TOOLS
ALWAYS WEAR
SAFETY GOGGLES
WEAR HEARING
PROTECTION
AVOID
PROLONGED
EXPOSURE TO
VIBRATION
SX235KTB
S
HORT
A
H
IR
AMMER
Rev. 05/02/02

Advertisement

loading
Need help?

Need help?

Do you have a question about the SX235KTB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sunex Tools SX235KTB

  • Page 1: Specifications

    SPECIFICATIONS SX235KTB Air Pressure ......90 PSI Blows Per Minute ....4,500 HORT Air Consumption....4 CFM Bore ........11/16"...
  • Page 2 Always check for • Do not remove any labels. Replace damaged, frayed or loose hoses and damaged labels. fittings, and replace immediately. Do not use quick detach couplings at tool. See instructions for correct set-up. SX235KTB Rev. 05/02/02...
  • Page 3 SX235KTB Short Air Hammer REF. DESCRIPTION PART NO. QTY. Body 847001 Rubber Gasket 847002 O-Ring 847003 Regulator 847004 Control Pin 847005 O-Ring 847006 Ball 275B17 Spring 275B18 Hose Joint 275B19 Rear Valve & Pin 847010 Valve Disk Front Valve 847012...
  • Page 4: Air Supply

    This product carries a ONE-YEAR warranty. Line pressure should be increased to compensate for unusually long air During this warranty period, Sunex Tools will repair or replace at our hoses (over 25 feet). Minimum hose diameter should be 1/4" I.D.
