SPS12/SPS20/SPS4050/SPS100
INSTALLATION INSTRUCTIONS • WARNING INFORMATION
SPECIFICATIONS
Model No.
SPS12 . . . . . . . . . . . . . . 24" . . . . . . . . . . . . . . . . . . 30"
SPS20 . . . . . . . . . . . . . . 24" . . . . . . . . . . . . . . . . . . 30"
SPS4050 . . . . . . . . . . . . 30" . . . . . . . . . . . . . . . . . . 30"
SPS100 . . . . . . . . . . . . . 36" . . . . . . . . . . . . . . . . . . 30"
SPS4050 - 40 AND 50 TON PRESS SHIELD
SPS100 - 100 TON PRESS SHIELD
Width
SPS12 - 12 TON PRESS SHIELD
SPS20 - 20 TON PRESS SHIELD
SPS4050 - shown on
5740AH
Height
© Copyright 2022, Sunex Tools
®
Rev. 07/15/22
