Sunex Tools SX278C Operating Instructions

Sunex Tools SX278C Operating Instructions

8 mm punch / flange tool

Advertisement

Quick Links

Operating Instructions • Warning Information • Parts Breakdown
Some dust created by power sanding, sawing, grinding, drilling,
and other construction activities contains chemicals known to
cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement
and other masonry products, and
• arsenic and chromium from
chemically-treated lumber.
Your risk from these exposures varies, depending on how often
you do this type of work. To reduce your exposure to these
chemicals: work in a well ventilated area, and work with
approved safety equipment, such as those dust masks that are
specially designed to filter out microscopic particles.
Punch Hole Size . . . . . . . . . . .8MM
Capacity . . . . . . . . . . . .14 Gauge
Air Inlet . . . . . . . . . . . . . .1/4 NPT
Hose Size . . . . . . . . . . . .3/8" I.D.
SX278C
SPECIFICATIONS
Air Pressure . . . . . . . . . . . . .90 PSI
Air Consumption . . . . . . . . .4 CFM
Length . . . . . . . . . . . . . . . . . . .10"
Net Weight . . . . . . . . . .3-1/2 Lbs.
1
ALWAYS READ
INSTRUCTIONS
BEFORE USING
POWER TOOLS
ALWAYS WEAR
SAFETY GOGGLES
WEAR HEARING
PROTECTION
AVOID
PROLONGED
EXPOSURE TO
VIBRATION
SX278C
8 MM P
UNCH
F
T
LANGE
OOL
Rev. 05/02/02
/

Advertisement

loading
Need help?

Need help?

Do you have a question about the SX278C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sunex Tools SX278C

  • Page 1 SPECIFICATIONS SX278C Punch Hole Size ...8MM Air Pressure ... . .90 PSI Capacity .
  • Page 2 Whip hoses can cause serious injury. Always check for damaged, frayed or loose hoses and fittings, and replace immediately. Do not use quick detach couplings at tool. See instructions for correct set-up. SX278C Rev. 05/02/02...
  • Page 3 SX278C 8MM Punch/Flange Tool Ref. # Item # Description Qty. Ref. # Item # Description Qty. 83701A Piston 83724 Air Valve Body 83702 Packing 83725 O-Ring 83703 Back-Up Ring 83726 Spring 83704 O-Ring 83727 Air Valve 83705 Cylinder 83728 Plug...
  • Page 4 This product carries a ONE-YEAR warranty. During this warranty period, Sunex Tools will repair or replace at our option any part or unit which proves to be defective in material or workmanship.
