Operating Instructions • Warning Information • Parts Break down
5000A
16 Speed Drill Press
SPECIFICATIONS
Power ...................................................................................3/4 HP
Power Source ..........................................................................115V
Spindle Taper ...........................................................................MT2
Chuck ....................................................................................... 5/8"
Speed Range .......................................................... 200-3850 RPM
Maximum Spindle Stroke ......................................................3-1/8"
Diameter of Column ..............................................................2-3/4"
Table Diameter ....................................................................11-1/2"
Height ..............................................................................61-13/16"
Shipping Weight ................................................................146 Lbs.
Caution:
Read and follow all safety rules and op er at ing instructions
before assembly and first use of this equipment
WARNING
Some dust created by power sanding, sawing, grinding,
drilling, and other construction activities contains chemi-
cals known to cause cancer, birth defects or other repro-
ductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks
and cement and other masonry
products, and
• arsenic and chromium from
chemically-treated lumber.
Your risk from these exposures varies, depending on
how often you do this type of work. To reduce your expo-
sure to these chemicals: work in a well ventilated area,
and work with approved safety equipment, such as
those dust masks that are specially designed to
filter out microscopic particles.
WARNING
This product may contain one or more chemicals known
to the State of California to cause cancer and birth
defects or other reproductive harm. Wash hands
thoroughly after handling.
1
5000A
rev. 11/04/13
Advertisement
Table of Contents
Related Manuals for Sunex Tools 5000A
Summary of Contents for Sunex Tools 5000A
- Page 1 Operating Instructions • Warning Information • Parts Break down 5000A 16 Speed Drill Press SPECIFICATIONS Power ...................3/4 HP Power Source ................115V Spindle Taper ................MT2 Chuck ..................5/8” Speed Range ............200-3850 RPM Maximum Spindle Stroke ............3-1/8” Diameter of Column ..............2-3/4"...
- Page 2 WARNING: ALWAYS KEEP ALERT Do not allow familiarity gained from fre quent use of radial drill press to cause a careless mistake. A careless frac tion of a second is sufficient to inflict severe per son al injury. 5000A rev. 11/04/13...
- Page 3 • Open chuck jaws completely by turning attached chuck key counter clockwise to the end. • Put a piece of scrap wood on the table to protect chuck nose. • Pull feeding handle down pressing the chuck against the scrap wood until arbor is secure on the spindle. 5000A rev. 11/04/13...
-
Page 4: Parts Breakdown
5000A 16 Speed Drill Press Parts Breakdown 5000A rev. 11/04/13... -
Page 5: Parts List
5000A 16 Speed Drill Press Parts List I ndex No. Part No. Description Qty. I ndex No. Part No. Description Qty. Base Power Plug Cord Washer Motor Bracket Support Bolt Bolt Column Support Clamp Nut Cap RS5000A05 Rack Adjusting Lever RS5000A06 Rack Collar Clamp... - Page 6 The proper drill speed for a given drill bit size is as follows: 5000A rev. 11/04/13...
-
Page 7: Operation
All of the ball bearings are packed with grease at the factory. They require no further lubrication Periodically lubricate the gear and rack table elevation mechanism, the splines (grooves) in the spindle, and the rack (teeth on the quill). 5000A rev. 11/04/13... -
Page 8: Safety Rules
10. Connect to power supply protected by a circuit breaker or time delay fuse. 11. Fasten base to floor before using the drill press. 12. Use only the chuck key provided by the manufacturer or a duplicate of it. 5000A rev. 11/04/13... - Page 9 If in doubt, use the next heavier gauge. The smaller the gauge number, the heavier the cord. Extension Cord Length Wire Size, A.W.G. 25 Feet 50 Feet 75 Feet 100 Feet 150 Feet 5000A rev. 11/04/13...
-
Page 10: Troubleshooting Guide
This product carries a ONE-YEAR warranty. During this warranty period, Sunex Tools will repair or replace at our option any part or unit which proves to be defective in material or workmanship.
