- Page 1 User’s Manual OLS5200E/EXL CyberPower Systems Inc. www.cyberpower.com K01-C000106-01...
-
Page 2: Important Safety Instructions
3.5mA. DO NOT INSTALL THE UPS WHERE IT WOULD BE EXPOSED TO DIRECT SUNLIGHT OR NEAR A STRONG CAUTION! The OLS5200E/EXL Battery module model are only HEAT SOURCE! qualified maintenance personnel may carry out installations. DO NOT BLOCK OFF VENTILATION OPENINGS AROUND... - Page 3 UNPACKING USB communication cable PowerPanel® Business Edition software CD Strap tie User’s manual Phone line Copyright © 2012 CyberPower Systems, Inc.
-
Page 4: Installing Your Ups System
This UPS is equipped with an auto-charge feature. When the power cord). The in/out power cord MUST be grounded. UPS is plugged into an AC outlet, the battery will automatically charge, even when the unit is switched off. Copyright © 2012 CyberPower Systems, Inc. -
Page 5: Basic Operation
Enable Power-Off in emergency from a remote location. 12. Output Circuit Breaker Provide output overload and fault protection. 13. Output Terminal Block Connect to your equipment. 14. Input Terminal Block Connect the AC Power to UPS. Copyright © 2012 CyberPower Systems,lnc. - Page 6 Replaceable fuse is accessible from the rear panel. It must be done by qualified personnel. 3. Output Connector Use this output Connector to connect the Battery module to the Power module or to the next Battery module. BPSE120V45A Copyright © 2012 CyberPower Systems, Inc.
- Page 7 Step 2: Connect the AC power to input terminal block, and the load to output terminal block. The line、neutral and ground must be connected correctly. Then use the cable ties to fix the AC wires to rings below the terminal blocks (as photograph 2). Step 3: Tighten the metal covers with M3 screws (as photograph 3). Copyright © 2012 CyberPower Systems, Inc.
- Page 8 Step 2: Use the battery cable of the Battery module to connect the Battery module to the Power module. Step 3: Rotate the battery cable retention bracket and tighten the two screws to fix battery cable. Copyright © 2012 CyberPower Systems, Inc.
- Page 9 Step 3: Use the battery cable to connect the 2 Battery module to the 1 Battery module. Step 4: Rotate the battery cable retention bracket and tighten the two screws to fix battery cable. Copyright © 2012 CyberPower Systems, Inc.
- Page 10 FAULT: This icon appears if there is a problem with the UPS. Please refer to “Event ID Descriptions”. Copyright © 2012 CyberPower Systems, Inc.
-
Page 11: Button Operation
Switch to bypass mode: When the main power is normal, ENTER/▲ + ESC/▼ press these two buttons simultaneously for 5 seconds, then UPS will enter to bypass mode. *) If utility power is connected，UPS will keep charging but cut off output. Copyright © 2012 CyberPower Systems, Inc. -
Page 12: Lcd Setup Functions
Press the “ESC” button simultaneously for 5 seconds to cancel and exit setting mode. Press the “ENTER” button simultaneously for 5 seconds to save all the settings you just do and exit setting mode. Copyright © 2012 CyberPower Systems, Inc. -
Page 13: Silencing Audible Alarms
Note: Some audible alarms (Over Temperature, Fan Fail, etc.) can’t be silenced. MANUAL BATTERY TEST Press the “ENTER” button simultaneously for 5 seconds to enter UPS self-testing while in AC mode, ECO mode, or converter mode. Copyright © 2012 CyberPower Systems, Inc. -
Page 14: Maintenance
Only use replacement batteries which are number of the correct replacement batteries. For battery certified by CyberPower Systems. Use of incorrect battery procurement, log onto www.cyberpower.com, or contact your type is an electrical hazard that could lead to explosion, fire, local dealer. -
Page 15: Technical Specifications
Operating Relative Humidity 20 to 90% Non-Condensing Management On-Device Features Self Test, Auto-Charge, Auto-Restart, Auto-Overload Recovery Connectivity Ports (1) Serial Port (RS232), (1) USB Port, SNMP/HTTP Capable (1) Expansion Port (With optional RMCARD 302) Copyright © 2012 CyberPower Systems, Inc. - Page 16 (± 1, 2, 3, 4, 5, 6, 7, 8, 9, 10%). When input frequency is out of synchronization window but within 40-70Hz, UPS can stay in line mode and output frequency is regulated at 50/60Hz+0.5% with load derating by 40%. Copyright © 2012 CyberPower Systems, Inc.
-
Page 17: Troubleshooting
2. Contact CyberPower for repair. CyberPower Systems Inc. www.cyberpower.com © Entire contents copyright 2015 CyberPower Systems Inc., All rights reserved. Reproduction in whole or in part without ® ® permission is prohibited. PowerPanel Business Edition and PowerPanel Personal Edition are trademarks of CyberPower Systems Inc.
