Ovislink IAS-2000 Quick Setup Manual

Internet access gateway

Advertisement

Quick Links

IAS-2000
Internet Access Gateway
Quick Setup Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IAS-2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ovislink IAS-2000

  • Page 1 IAS-2000 Internet Access Gateway Quick Setup Guide...
  • Page 2: Package Contents

    1. Introduction 1.1 Preface This Quick Installation Guide provides instructions and reference material for getting started with IAS-2000. This guide will also show you how to connect IAS-2000 to other network equipments. 1.2 Package Contents IAS-2000 x 1 CD-ROM x 1...
  • Page 3: Hardware Installation

    Rear Panel Power Switch Power Socket: System System The power cord attaches here. 1.3.2 Hardware Installation 1. Connect the power cord to the power socket on the rear panel. English Internet Access Gateway -2000...
  • Page 4: Getting Started

    7 such as the Access Point. However, after the Access Point hardware reset, IAS-2000 should not be able to connect to Access Point while connecting with a straight cable unless the cable was pulled out and plug-in again.
  • Page 5: Common Settings

    In the Quick Installation Guide, two common settings are described below that allows you to use the Configuration Wizard utility to speed up the configuration process of IAS-2000. Please refer to section 2.1 Hotel for hotel environment and section 2.2 Campus for campus environment.
  • Page 6 After completing the hardware installation and successfully logging into the configuration screen, IAS-2000 can then be configured from the web browser. In the hotel environment, it is convenient to use the built-in authentication server to quickly setup the services. One example is to set Local User authentication method in the Configuration Wizard for employees and for customers.
  • Page 7 The Configuration Wizard will appear in a separate browser window. Click Next to begin. Step 1: Change Admin’s Password Enter a new password for the admin account and retype it in the verify password field (twenty characters maximum and no spaces allowed). Click Next to continue.
  • Page 8 NTP Server: Enter the URL of external time server for IAS-2000 time synchronization or use the default. DNS Server: Enter a DNS Server provided by your ISP (Internet Service Provider).
  • Page 9 LAN1 clients must be configured with an IP address manually. Enable DHCP Server: When the option is selected, IAS-2000 will automatically provide the necessary IP addresses to all LAN1 clients. Click Next to continue. Step 7: Set LAN1 DHCP Server...
  • Page 10 ADD bottom. Click Next to continue. Step 10: Restart Click Restart to save the current settings and restart IAS-2000. The Setup Wizard is now completed. English Internet Access Gateway -2000...
  • Page 11 Now, the base configuration for Hotel environment has been finished! If all the steps are done properly, IAS-2000 can be further connected to the managed network to experience the controlled network access environment. Firstly, connect an end-user device to the network at IAS-2000’s Public LAN and set the end-user device to obtain an IP...
  • Page 12 Now, you can browse the network or surf the Internet! 2.1 Campus IAS-2000 used in the campus environment is usually connected to LDAP Server as an external authentication server. Please refer to the following figure on connecting IAS-2000 and ADSL modem.
  • Page 13 Click the System Configuration from the top menu and the System Configuration screen will appear. Then, click on Configuration Wizard icon. Click Run Wizard to begin the Configuration Wizard. The Setup Wizard will appear in a separate browser window. Click Next to begin. Step 1: Change Admin’s Password Enter a new password for the admin account and retype it in the verify...
  • Page 14 NTP Server: Enter the URL of external time server for IAS-2000 time synchronization or use the default. DNS Server: Enter a DNS Server provided by your ISP (Internet Service Provider).
  • Page 15 LAN1 clients. (Note: Be sure that IP address assigned in this range is NOT used in other setting through IAS-2000.) Domain Name: Enter a domain name provided by your ISP (e.g. yahoo.com.tw).
  • Page 16 WINS Server: Enter the IP address of the WINS Server (Windows Internet Naming Service Server). This field is optional. Preferred DNS Server: The DNS Server settings are provided by your ISP. Only the Preferred DNS Server field is mandatory. Contact your ISP if you are unsure of the DNS Server settings.
  • Page 17 Windows AD to access the LDAP server. Click Next to continue. Step 7: Restart Click Restart to save the current settings and restart IAS-2000. The Setup Wizard is now completed. English Internet Access Gateway -2000...
  • Page 18 Now, the base configuration for Campus environment has been finished! If all the steps are done properly, IAS-2000 can be further connected to the managed network to experience the controlled network access environment. Firstly, connect a user-end device to the network at IAS-2000’s Public LAN and set to obtain an IP address automatically.
  • Page 19 Congratulation! Logon page appearing means IAS-2000 has been installed and configured successfully. Now, you can browse the network or surf the Internet! For further information, please refer to the user’s manual English Internet Access Gateway -2000...
