DEsCRipTion
(see fig. 1)
a
ON/STAND-BY button
B
+/- adjustment buttons
C MODE button (selects the operating mode)
D "ECO plus" button
E
Timer button
f
Swing button
g Remote control receiver
H Indicator light
i Air intake grille
J
Filter
UsE

installation

- The appliance can be used on any horizontal surface.
Do not overload the electrical circuit. Avoid using the
same socket for other appliances.
Electrical connection
- Before connecting the plug to the power outlet,
make sure that the voltage of your electrical system
corresponds to the voltage shown on the appliance
rating label and the outlet you are going to use is in
good condition.
- THIS APPLIANCE COMPLIES WITH DIRECTIVE 2004/108/
EEC ON RADIO INTERFERENCE SUPPRESSION.

mounting the base

- Fit the two parts of the base together, matching the
guide pins on the front with the recesses on the back
and snapping the two clips into place (fig. A and fig. B).
- Turn the appliance upside down and fix the base to the
body with the 6 screws supplied (fig. C).

operation and use

1. Plug into the mains socket.
2. The appliance emits a beep. The indicator light (H) comes
on and remains lit while the appliance is powered.
3. The appliance switches to stand-by. A dot flashing on
the display means the tip over device has been activated.
See paragraph: "Safety functions".
4. Press the ON/STAND-BY (a) to turn the appliance on.
It begins heating the room according to the current
settings.
5. Press the MODE button (C) to select one of the following
operating modes:
Description/Use
fan
freeze prevention
Heating 1
Heating 2
Heating 3
5.1 fan
In this mode, only the fan operates and the appliance does
not heat the room.
5.2 freeze prevention
In this mode, the appliance keeps the room at a temperature
of 7°C to avoid freezing.
5.3 Heating 1, 2 and Heating 3
In this mode, the desired temperature can be selected by
pressing the adjustment buttons + and – ( B ):
Heating 1
-
The appliance operates at low power, reducing noise
levels and energy consumption to a minimum.
- Heating 2
The appliance operates at medium power.
Heating 3
-
The appliance operates at high power to heat the room
rapidly.
6. "ECo plus" function
The "ECO plus" function is available in Heating 1, 2 and 3
modes only.
To activate the function, press the "ECO plus" button (D). When
this function is active the appliance automatically sets the
most appropriate power level to guarantee optimum comfort
while reducing energy consumption. While the "ECO plus"
function is active, the appliance may switch automatically to
a lower heating power than the one displayed.
7. To distribute the air flow over a wider surface, press the
swing button (f) . The appliance starts swinging to
the right and left. To stop the appliance in the desired
position, simply press the swing button (f) again.
8. To turn the appliance off, press the ON/STAND-BY button
(a). The display may visualise a countdown for about 6
seconds.
please note: Room temperature can be displayed in
either °C or °F. To change the unit of measurement for the
temperature, press and hold the + button for a few seconds,
then release.
