Installation and Owner's Manual
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other
fl ammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light the appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
the fi re department.
Installation and service must be performed
by a qualifi ed installer, service agency or the
gas supplier.
4001839-12
©2011, Miles Industries Ltd.
L
EGEND
DV Gas Insert (Logs)
739ILN (NG) & 739ILP (LPG)
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
Manufactured by
MILES INDUSTRIES LTD., British Columbia, Canada
www.valorfi replaces.com
I NSTALLE R
Lea ve t his ma nua l
with t he applianc e.
C ON SU MER
Re tain t his manua l
for f uture ref e re nce.
Please read this manual BEFORE installing
and operating this appliance.
This appliance may be installed in an
after-market permanently located,
manufactured (mobile) home where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certifi ed kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purposes such as drying clothes, etc.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Massachusetts: The piping and fi nal
gas connection must be performed by a
licensed plumber or gas fi tter in the State of
Massachusetts.
Ce guide est disponible en français sur demande.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 739ILN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Legend 739ILN

  • Page 1 EGEND DV Gas Insert (Logs) 739ILN (NG) & 739ILP (LPG) Installation and Owner’s Manual I NSTALLE R Lea ve t his ma nua l HOT GLASS WILL with t he applianc e. CAUSE BURNS. DO NOT TOUCH GLASS C ON SU MER UNTIL COOLED.
  • Page 2 Thank You ... For purchasing a Valor by Miles Industries. Your new radiant gas heater is a technical appliance that must be installed by a qualifi ed dealer. Each Valor fi replace is fully tested during the production process for your safety and comfort. Your unit has been professionally installed by: Dealer Name _______________________________________ Phone Number ______________________________________...
  • Page 3: Safety And Your Fireplace

    Safety and Your Fireplace Safety and Your Fireplace Please Read and Carefully Follow all Safety Warnings and Operating Instructions Contained in Your Owners Manual (Replacement Manuals are available by contacting our service department at 1-800-468-2567 or visit www.valorfi replaces.com). withdraw in the event of accidental Please Follow These Important contact with a hot surface.
  • Page 4: Table Of Contents

    Table of Content ◊ Safety and Your Fireplace ................3 Safety and Warning Information..............5 Specifi cations ....................6 Overview ......................7 Dimensions ....................8 Cavity ......................8 Clearances ......................9 Venting ......................10 Installation Planning ..................11 Existing Fireplace Preparation ..............11 Appliance Preparation .................12 Gas Supply Installation ................15 Ceramic Bricks Installation .................16 Ceramic Logs Installation ................16 Window Refi...
  • Page 5: Safety And Warning Information

    Safety and Warning Information OWNER’S INFO READ and UNDERSTAND all instructions carefully This unit MUST be used with a vent system as before starting the installation. FAILURE TO FOLLOW described in this installation manual. NO OTHER vent these installation instructions may result in possible fi re system or components MAY BE USED.
  • Page 6: Specifi Cations

    Input Minimum (Btu/h) 10.0 Manifold Pressure (in Conversion Kits w.c.) The 739IL Legend G3 is supplied as natural gas or 11.0 Minimum Supply propane gas and is fi eld convertible between fuels. See Pressure (in w.c.) instructions packaged with the conversion kit for further 10.0...
  • Page 7: Overview

    Overview INSTALLATION This appliance may ONLY be installed in an existing unaltered, functioning solid-fuel burning fi replace with a working fl ue and constructed of non-combustible material. DO NOT install into combustible construction. This appliance is NOT APPROVED for installation with a zero clearance kit. Chimney Terminal Cap Flashing 2 x 3”...
  • Page 8: Dimensions

    Dimensions INSTALLATION 28-5/8” (727 mm) 19-1/2” (495 mm) 12” (305 mm) or 12-5/8” (321 mm) Varies with outer trim options Optional Outer Trim or Surround sold separately 9-3/8” (238 mm) or 10” (254 mm) Varies with outer trim options 20” (508 mm) Gas inlet Gas connection...
  • Page 9: Clearances

    Clearances INSTALLATION WARNING Some materials or items, altough safe, may discolor, warp, crack, peel, and Some materials or items, altough safe, may discolor, warp, crack, peel, and so on because of the heat produced by the fi replace. Avoid placing candles, so on because of the heat produced by the fi...
  • Page 10: Venting

    Venting INSTALLATION Typical Vent Installation See list of approved Venting Accessories on page 29 of this manual. Vent Location The vent terminal must be located through the Terminal Cap roof. This direct vent appliance is designed to opreate when an undistrubed airfl ow hits the outside vent terminal from any direction.
  • Page 11: Installation Planning

    Installation Planning INSTALLATION Installer—READ THIS FIRST 1. YOU NEED TO KNOW FROM THE Tools and supplies required HOMEOWNER what accessories (surround, • Packing knife door, etc.) will be installed with this fi replace; • Screwdriver set 2. Unpack the appliance. •...
  • Page 12: Appliance Preparation

    Existing Fireplace Preparation INSTALLATION Gas Line Routing Combustible Mantels Plan the routing of the gas line before proceeding. Combustible mantel clearances must conform to those Utilize the existing hole for the gas line of the factory- required for the original solid-fuel fi replace into which built fi...
  • Page 13 Appliance Preparation INSTALLATION Window Removal The window is held in place by four spring-loaded bolts, two at the top and two at the bottom. 1. To remove the window, turn each bolt a quarter turn to disengage the bolt pin. 2.
  • Page 14 Appliance Preparation INSTALLATION Venting Installation IMPORTANT: This appliance’s venting system is room sealed and therefore, does not require room air to be used in the combustion process. 1. Rough-in two 3” diameter vent liners into the existing chimney system from the roof. Be careful not to tear or damage the liners in the process.
  • Page 15: Gas Supply Installation

    Gas Supply Installation INSTALLATION The gas supply inlet connection is a 3/8” NPT female Pressure Test Points connector and is located on the left hand side of the The minimum supply pressure is given in the section control valve. Specifi cations of this manual—page 6. All piping and connections must be tested for leaks after installation or servicing.
  • Page 16: Ceramic Bricks Installation

    Ceramic Bricks Installation INSTALLATION The following guidelines apply for all brick liners. 4. Rotate the anchor up and out of the way and slide the right hand side panel against the fi rebox side. 1. Inside the fi rebox, on the top of each side, release Rotate the anchor back down to hold the panel.
  • Page 17 Ceramic Logs Installation INSTALLATION 2. Place the rear log centering it side to side in the 5. Identify the right cross log; it has fi rebox. Position forward until it sits against the a hole under on of its end and it is sheet metal return behind the burner.
  • Page 18: Window Refi Tting

    Window Refi tting INSTALLATION 1. To refi t the window, hook its top part to the fi rebox’s opening frame. Make sure that the wider part of the window frame is at the bottom. 2. While you hold it, push in and turn the two top spring-loaded bolts a quarter turn to engage their pin.
  • Page 19: Operation Check & Aeration Settings Adjustment

    Operation Check & Aeration Settings Adjustment INSTALLATION In a few unusual installations, the fl ame picture may Operation Check be improved by adjusting the aeration. The need for Turn the fi replace fl ame up and down using the adjustment should be determined only by operating the remote control to confi...
  • Page 20: Owner's Information

    Owner’s Information OWNER’S INFO We have consulted with ceramic glass manufacturers WARNING and they cannot offer a defi nitive solution to this prob- lem. Dealers have tried various cleaning products with EXTREMELY HOT!!! varying results. The following are recommendations Some parts of your fi replace are EXTREMELY only and are not meant to guarantee results.
  • Page 21 Owner’s Information OWNER’S INFO To refi t the window: The appliance area must always be kept clear and free from combustible materials, gasoline and other 1. To refi t the window, fl ammable vapors and liquids. hook its top part to the fi...
  • Page 22 Owner’s Information OWNER’S INFO (including pilot) Lighting, Operation and Rating Information How to Turn Your Fireplace OFF Familiarize yourself with each of these methods before WARNING operating your fi replace. DO NOT ATTEMPT TO TOUCH THE DATA PLATE Handset and Wall Switch: Press and hold the OFF WHILE THE FIREPLACE IS STILL HOT! Let the button for a second.
  • Page 23: Remote Control Operation

    Remote Control Operation OWNER’S INFO NOTE: Before using the remote control system for the fi rst time, the receiver and the handset must be synchronized. See the section Remote Control Initial Set-up on page 18 in this manual. Your fi replace remote control helps you get the comfort, convenience and aesthetics you want from your gas fi replace. The remote controls your fi...
  • Page 24 Remote Control Operation OWNER’S INFO Operation Modes MAN MODE —Manual Mode. You can use this mode to adjust the flame height up or down. ☼ TEMP MODE —Daytime Temperature Mode (appliance must have pilot ignited): The room temperature is TEMP measured and compared to the set temperature.
  • Page 25 Remote Control Operation OWNER’S INFO Temperature Use this setting when you come in and want to enjoy a set temperature. MODE or the ☽ 1. Select either the ☼ MODE by briefly pressing the SET button. TEMP TEMP 2. Hold the SET button until the TEMP display flashes. 3.
  • Page 26: Options

    Remote Control Operation OWNER’S INFO Low Battery Indication CAUTION Remote handset: BATT will appear on the display when DO NOT USE a screwdriver or other metallic object the battery needs to be replaced. to remove the batteries from the battery box or the Replace with one 9 V alkaline battery.
  • Page 27: Lighting Instructions

    Lighting Instructions OWNER’S INFO FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING : If you do not follow these instructions exactly a re or ex losion ay result causin ro erty da a e ersonal in ury or loss of life A.
  • Page 28: Wiring Diagram

    Wiring Diagram INSTALLATION Optional Wall Switch Kit 1265WSK Connector Yellow GV60 Wiring Diagram...
  • Page 29: Venting Accessories

    Venting Accessories INSTALLATION APPROVED DIRECT VENT SUPPLIERS FOR VALOR MODELS 739 & RF24DV Venting Parts Code / availability by Manufacturer Venting Parts Description Standard Co-axial 46DVA-VC 4DT-VC TM-4VT — HSDV4658-1313 — High Wind Co-axial 46DVA-VCH — — SV4CGV — — Extended Co-axial 46DVA-VCE —...
  • Page 30: Warranty

    Warranty OWNER’S INFO If you have a problem with this unit, please contact your dealer or supplier immediately. Under no circumstances should you attempt to service the unit in any way by yourself. The warranties in paragraphs 1 and 2 are provided only to the fi rst purchaser/user of this unit, are not transferable and are subject to the conditions and limitations in paragraphs 3, 4 and 5.
  • Page 31: Spare Parts

    Spare Parts OWNER’S INFO Part Part Code Description Code Description Number Number Exhaust Slide Assembly 4001133 Module Gasket—Left 4000181 Exhaust Slide Gasket 4000176 Olive Nut for Pilot Pipe 220K913 Fan Closure Plate 4001136 Pipe—Valve to Pilot 4001838 Port Cover 4001820AH Thermal Switch Retainer 4001519 Log Support...
  • Page 32 Spare Parts OWNER’S INFO 12 13...
  • Page 33 Thank You ... For purchasing a Valor by Miles Industries. Your new radiant gas heater is a technical appliance that must be installed by a qualifi ed dealer. Please circle where appropriate - ask your installer or your dealer if in doubt. The information provided will be used for customer records only.
  • Page 34 Tape Shut Fold here Postage needed Miles Industries Ltd. 190 - 2255 Dollarton Highway North Vancouver, BC V7H 3B1 Canada Online Warranty registration at www.valorfi replaces.com Thank you for choosing a Valor Product...
