DANGER
!
A barrier designed to reduce the risk of burns from the hot
viewing glass is provided with this appliance and shall be
installed for the protection of children and other at-risk
individuals.
!
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
— Do not store or use gasoline or other
fl ammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
▪ Do not try to light any appliance.
▪ Do not touch any electrical switch; do
not use any phone in your building.
▪ Leave the building immediately.
▪ Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
▪ If you cannot reach your gas supplier,
call the fi re department.
— Installation and service must be
performed by a qualifi ed installer, service
agency or the gas supplier.
4003899-06
©2015, Miles Industries Ltd.
L
EGEND
Gravity Vent Gas Insert
738JLN (NG) & 738JLP (LPG)
Installation & Owner's Manual
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
L e a v e t h i s m a n u a l
w i t h t h e a p p l i a n c e .
R e t a i n t h i s m a n u a l
f o r f u t u r e r e f e r e n c e .
Please read this manual
BEFORE installing and
operating this appliance.
This manual contains instructions to install the
ENGINE ONLY. A front is also REQUIRED to
complete this installation. A barrier screen is pro-
vided with the front. Refer to the manual sup-
plied with the front for installation.
This appliance may be installed in an
after-market permanently located,
manufactured (mobile) home where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certifi ed kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purposes such as drying clothes, etc.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Ce guide est disponible en français sur demande.
I N S TA L L E R
C O N S U M E R
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Legend 738JLN
Summary of Contents for Legend 738JLN
- Page 1 EGEND Gravity Vent Gas Insert 738JLN (NG) & 738JLP (LPG) Installation & Owner’s Manual DANGER I N S TA L L E R L e a v e t h i s m a n u a l HOT GLASS WILL w i t h t h e a p p l i a n c e .
-
Page 2: Table Of Contents
Table of Content FOR THE OWNER FOR THE QUALIFIED INSTALLER Safety Precautions ..........3 Specifi cations ............13 Safety and Your Fireplace ........4 Overview..............14 Owner’s Information ..........5 Dimensions ............15 Operating Your Fireplace for the First Time ....5 Cavity .............. -
Page 3: Safety Precautions
Safety Precautions READ and UNDERSTAND all instructions carefully Due to the high temperature, the appliance should be before starting the installation. FAILURE TO FOLLOW LOCATED out of traffi c areas and away from furniture these installation instructions may result in possible fi re and draperies. -
Page 4: Safety And Your Fireplace
Safety and Your Fireplace Safety and Your Fireplace Please Read and Carefully Follow all Safety Warnings and Operating Instructions Contained in Your Owner’s Manual (Replacement Manuals are available by contacting our service department at 1-800-468-2567 or visit www.valorfi replaces.com). withdraw in the event of accidental Please Follow These Important contact with a hot surface. -
Page 5: Owner's Information
OWNER’S Owner’s Information INFORMATION Thank You ... WARNING For purchasing a Valor by Miles Industries. Your new EXTREMELY HOT!!! radiant gas heater is a technical appliance that must be installed by a qualifi ed dealer. Each Valor fi replace • READ the SAFETY information on pages is fully tested during the production process for your 3 and 4 of this manual BEFORE operating safety and comfort. -
Page 6: Cleaning Your Fireplace
OWNER’S Owner’s Information INFORMATION Cleaning Your Fireplace To remove the window for cleaning: 1. Unhook the front with WARNING barrier screen. 2. On the window, turn DO NOT TOUCH THE GLASS WHILE IT IS HOT! each bolt a quarter turn Let the fireplace cool first before touching it. -
Page 7: Checking Pilot And Burner Flames
OWNER’S Owner’s Information INFORMATION Replacing Batteries 5. Replace the front or trim with the barrier screen attached. WARNING WARNING DO NOT ATTEMPT TO CHANGE THE BATTERIES FOR SAFETY PURPOSE, ensure the barrier WHILE THE FIREPLACE IS STILL HOT! Let the screen is re-installed on the fi... -
Page 8: Your Fireplace's Vent Safety Switch
OWNER’S Owner’s Information INFORMATION Your Fireplace’s Vent Safety Switch This appliance is equipped with a vent safety switch which, when activated, will turn off the burner and pilot if the vent is blocked, disconnected, or if there is excessive down draught. If the safety switch is activated, wait for it to cool off before trying to light the appliance again. -
Page 9: Remote Control Operation
OWNER’S Remote Control Operation INFORMATION Your fi replace remote control helps you get the comfort, convenience and aesthetics you want from your gas fi replace. The remote controls your fi replace in different ways. IMPORTANT: BEFORE YOU BEGIN, please note that on this system, the settings of time, temperature and automatic ON/OFF can only be programmed when the function display is fl... - Page 10 OWNER’S Remote Control Operation INFORMATION Setting the fl ame Use this setting when you want a particular fl ame level. For instance, you want to watch fl ames burn at their highest level and you don’t mind if the room is too hot.
-
Page 11: Options
OWNER’S Options INFORMATION Required Kits* Other Accessories 770ZCK—Zero Clearance Kit Venting 759EBL—Enamel Liners Approved venting accessories as per local codes. Conversion Kit Inner Fronts (choose one) 738PGK—Conversion Kit to Propane Gas 741—Contemporary Front with Barrier Screen 4003360 738NGK—Conversion Kit to Natural Gas 742—Traditional Cast Front with Barrier Screen 4003293 Hearth Gate 743—FenderFire Double Door Front... -
Page 12: Lighting Instructions
OWNER’S Lighting Instructions INFORMATION FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot, which must be lighted by hand. When lighting the pilot, follow these instructions exactly. -
Page 13: Specifi Cations
3.95 w.c.) Conversion Kits Minimum Supply 11.0 Pressure (in w.c.) The 738 Legend G3 is supplied as natural gas or propane gas and is fi eld convertible between fuels. Maximum Supply 10.5 14.0 See instructions packaged with the conversion kit Pressure (in w.c.) -
Page 14: Overview
QUALIFIED Overview INSTALLER This appliance, as supplied, may ONLY be installed in an existing unal- tered, functioning solid-fuel burning fi replace with a working fl ue and con- structed of non-combustible material. This appliance is APPROVED for installation into combustible type con- struction only when using the 770ZCK Zero Clearance Kit (see separate instructions packaged with the kit for details). -
Page 15: Dimensions
QUALIFIED Dimensions INSTALLER 28-5/8” (727 mm) 19-1/2” (495 mm) 12 - 14” (305 - 357 mm) Varies with outer trim options Optional Outer Trim or Surround sold separately 7-7/8” - 9-7/8“ (200 - 251 mm) Varies with outer trim options 20”... -
Page 16: Clearances
QUALIFIED Clearances INSTALLER WARNING Some materials or items, although safe, may discolor, shrink, warp, crack, peel, and so on because of the heat produced by the fi replace. Avoid placing candles, paintings, photos, and other items sensitive to heat around the fi replace. Combustible Mantel Clearances Mantel Pro- 1”... -
Page 17: Venting
QUALIFIED Venting INSTALLER Vent Location Typical Vent Installation The vent terminal must be located through the roof. This gravity vent appliance is designed to opreate when an undistrubed Terminal Cap airfl ow hits the outside vent terminal from any direction. Check local codes for allowable vertical vent termination. -
Page 18: Existing Fireplace Preparation
QUALIFIED Installation Planning INSTALLER Only qualifi ed licensed or trained personnel should install this appliance. Installer—READ THIS FIRST 1. YOU NEED TO KNOW FROM THE 9. Install the remote control system. HOMEOWNER what accessories (surround, 10. Install bricks and logs. door, etc.) will be installed with this fi... -
Page 19: Installation
QUALIFIED Existing Fireplace Preparation INSTALLER Existing Glass Doors and Wire Screens Attach Warning Conversion Plate to Existing Fireplace (label supplied loose with 738JL Existing glass doors must be permanently removed heater) prior to installing the 738JL insert. Attach the “This fi replace has been converted...” Combustible Mantels label to the existing fi... -
Page 20: Connect Vent
QUALIFIED Installation INSTALLER Connect Vent IMPORTANT: This appliance’s venting system requires room air to be used in the combustion process. 1. Rough-in one 3” diameter vent liner into the existing chimney system from the roof. Be careful not to tear or damage the liner in the process. -
Page 21: Connect Gas Supply
QUALIFIED Installation INSTALLER Connect Gas Supply Pressure Test Points The gas supply inlet connection is a 3/8” NPT female The minimum supply pressure is given in the section connector and is located on the left hand side of the Specifi cations of this manual—page 13. control valve. -
Page 22: Check Ignition Spark
QUALIFIED Installation INSTALLER Check ignition spark The pilot burner and electrode unit are at the left end of the burner. Push in the lighting knob and turn it counter-clockwise through the “IGN” position to “PILOT”. A spark should fl ash across from the pilot electrode to the pilot burner shield as shown below. -
Page 23: Install Ceramic Bricks
QUALIFIED Installation INSTALLER Install Ceramic Bricks 4. Rotate the anchor up and out of the way and slide the right hand side panel against the fi rebox side. The following guidelines apply for all brick liners. Rotate the anchor back down to hold the panel. 1. -
Page 24: Install Ceramic Logs
QUALIFIED Installation INSTALLER Install Ceramic Logs Unpack the ceramic logs very carefully to avoid damaging the fragile material. Install the logs as shown below. Please note that the position of the logs is critical to ensure proper performance of the appliance. 1. - Page 25 QUALIFIED Installation INSTALLER 4. Place the front right log on the burner and slide it to 6. Place the lower end of the center right log onto the the left against the front left log. pin on the front right log. Rest the narrow end in the notch into the rear log.
-
Page 26: Re-Install And Check Window
QUALIFIED Installation INSTALLER Re-install and Check Window 1. To refi t the window, hook its top part to the fi rebox’s opening frame. Make sure that the wider part of the window frame is at the bottom. 2. While you hold it, push in and turn the two top spring- loaded bolts a quarter turn to engage their pin. -
Page 27: Install Front, Trim And Barrier Screen
QUALIFIED Installation INSTALLER Install Front, Trim and Barrier Screen Install the front and trim chosen by the customer for their fi replace. Install as well the barrier screen which is provided with the front. Show the customer remove the front and also how to access the controls when the front is installed. -
Page 28: Warranty
OWNER’S Warranty INFORMATION If you have a problem with this unit, please contact your dealer or supplier immediately. Under no circumstances should you attempt to service the unit in any way by yourself. The warranties in paragraphs 1 and 2 are provided only to the fi... -
Page 29: Spare Parts
OWNER’S Spare Parts INFORMATION Part Part Code Description Code Description Number Number Exhaust Slide Assembly 4000127 Warning Hot Glass Plate 4003093 Port Cover 4001820AH Thermocurrent Interruptor 4000202 Log Support 4004353 GV34 Valve Assembly NG 4003096 Side Bricks Anchors (2) 4001283 GV34 Valve Assembly LPG 4003109 Top Mounting Bracket... - Page 30 OWNER’S Spare Parts INFORMATION 35a, 35b...
-
Page 31: Miles Industries Ltd
Thank You ... For purchasing a Valor by Miles Industries. Your new radiant gas heater is a technical appliance that must be installed by a qualifi ed installer. Please fi ll in the information below. The information provided will be used for customer records only. -
Page 32: Miles Industries Ltd
Tape Shut Fold here Postage needed Miles Industries Ltd. 190 - 2255 Dollarton Highway North Vancouver, BC V7H 3B1 Canada Online Warranty registration at www.valorfi replaces.com Thank you for choosing a Valor Product...
