738BXN (NG) & 738BXP (LPG)
Installation & Operating Instructions
!
WARNING
!
WARNING
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light the appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
the fire department.
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
4001379-06
©2010, Miles Industries Ltd.
L
egend
Gravity Vent Gas Insert
WARNING
HOT GLASS WILL
HOT GLASS WILL
HOT GLASS WILL
CAUSE BURNS.
CAUSE BURNS.
CAUSE BURNS.
DO NOT TOUCH GLASS
DO NOT TOUCH GLASS
DO NOT TOUCH GLASS
UNTIL COOLED.
UNTIL COOLED.
UNTIL COOLED.
NEVER ALLOW CHILDREN
NEVER ALLOW CHILDREN
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
TO TOUCH GLASS.
TO TOUCH GLASS.
Manufactured by
MILES INDUSTRIES LTD., British Columbia, Canada
www.valorfireplaces.com
INSTALLER: Leave this manual
with the appliance.
CONSUMER: Retain this manual
for future reference.
Please read this manual BEFORE
installing and operating this
appliance.
This appliance may be installed in an
after-market permanently located,
manufactured (mobile) home where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purposes such as drying clothes, etc.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Massachusetts: The piping and final
gas connection must be performed by a
licensed plumber or gas fitter in the State of
Massachusetts.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Legend 738BXN (NG)
Summary of Contents for Legend 738BXN (NG)
- Page 1 egend Gravity Vent Gas Insert 738BXN (NG) & 738BXP (LPG) Installation & Operating Instructions WARNING WARNING WARNING HOT GLASS WILL HOT GLASS WILL HOT GLASS WILL INSTALLER: Leave this manual CAUSE BURNS. CAUSE BURNS. CAUSE BURNS. with the appliance. DO NOT TOUCH GLASS DO NOT TOUCH GLASS DO NOT TOUCH GLASS CONSUMER: Retain this manual...
- Page 2 Thank You ... For purchasing a Valor by Miles Industries. Your new radiant gas heater is a technical appliance that must be installed by a qualified dealer. Each Valor fireplace is fully tested during the production process for your safety and comfort. Your unit has been professionally installed by: Dealer Name _______________________________________ Phone Number ______________________________________...
-
Page 3: Table Of Contents
Table of Content Safety and Warning Information..............4 ◊ Specifications ....................5 Overview ......................6 ◊ Dimensions ....................7 Cavity ......................7 ◊ Clearances ......................8 Venting ......................9 Installation Planning ..................10 Existing Fireplace Preparation ..............10 Appliance Preparation .................11 Supply Gas ....................13 Ignition Spark Check ...................14 ◊ Remote Control Preparation ...............15 Ceramic Bricks .....................16 Ceramic Logs ....................16... -
Page 4: Safety And Warning Information
Safety and Warning Information READ and UNDERSTAND all instructions carefully This unit MUST be used with a vent system as before starting the installation. FAILURE TO FOLLOW described in this installation manual. NO OTHER vent these installation instructions may result in possible fire system or components MAY BE USED. -
Page 5: Specifications
Conversion Kits Minimum Supply 11.0 Pressure (in w.c.) The 738BX Legend G3 is supplied as natural gas or propane gas and is field convertible between fuels. See Maximum Supply 10.5 14.0 instructions packaged with the conversion kit for further Pressure (in w.c.) -
Page 6: Overview
Overview This appliance, as supplied, may ONLY be installed in an existing unaltered, functioning solid-fuel burning fireplace with a working flue and constructed of non-combustible material. This appliance is APPROVED for installation into combustible type construction only when using the 770ZCK Zero Clearance Kit (see separate instructions packaged with the kit for details). -
Page 7: Dimensions
Dimensions 28-5/8” (727 mm) 19-1/2” (495 mm) 12” (305 mm) or 12-5/8” (321 mm) Varies with outer trim options Optional Outer Trim or Surround sold separately 7-7/8” (200 mm) or 8-1/2” (216 mm) Varies with outer trim options 20” (508 mm) Gas inlet Gas connection Cavity... -
Page 8: Clearances
Clearances WARNING Some materials or items, altough safe, may discolor, warp, crack, peel, and so on because of the heat produced by the fireplace. Avoid placing candles, paintings, photos, and other items sensitive to heat around the fireplace. Combustible Mantel Clearances Mantel 1”... -
Page 9: Venting
Venting Vent Location Typical Vent Installation The vent terminal must be located through the roof. This gravity vent appliance is designed to opreate when an undistrubed Terminal Cap airflow hits the outside vent terminal from any direction. Check local codes for allowable vertical vent termination. Flashing Vent Materials Use a 3”... -
Page 10: Installation Planning
Installation Planning Installer—READ THIS FIRST 13. Install the remote control handset wall holder. 1. YOU NEED TO KNOW FROM THE HOMEOWNER what accessories (surround, 14. Instruct the homeowner on the operation and door, etc.) will be installed with this fireplace; maintenance of the fireplace. -
Page 11: Appliance Preparation
Existing Fireplace Preparation Existing Glass Doors and Wire Screens Attach Warning Conversion Plate to Existing Fireplace (label supplied loose with 738BX Existing glass doors must be permanently removed heater) prior to installing the 738BX insert. Attach the “This fireplace has been converted...” Combustible Mantels label to the existing fireplace using screws or other Combustible mantel clearances must conform to those... -
Page 12: Venting Installation
Appliance Preparation Venting Installation IMPORTANT: This appliance’s venting system requires room air to be used in the combustion process. 1. Rough-in one 3” diameter vent liner into the existing chimney system from the roof. Be careful not to tear or damage the liner in the process. -
Page 13: Supply Gas
Supply Gas The gas supply inlet connection is a 3/8” NPT female Pressure Test Points connector and is located on the left hand side of the The minimum supply pressure is given in the control valve. subsection Ratings of this manual—page 5. All piping and connections must be tested for leaks after installation or servicing. -
Page 14: Ignition Spark Check
Ignition Spark Check The pilot burner and electrode unit are at the left end of the burner. Push in the lighting knob and turn it counter-clockwise through the “IGN” position to “PILOT”. A spark should flash across from the pilot electrode to the pilot burner shield as shown below. Thermostat Knob Gas Control Knob... -
Page 15: Remote Control Preparation
Remote Control Preparation CAUTION CAUTION DO NOT USE a screwdriver or other metallic object DO NOT PUT BATTERIES IN THE REMOTE to remove the batteries from the receiver or the CONTROL RECEIVER until the wires are connected to the burner control unit as short- handset! This could cause a short circuit to the receiver. -
Page 16: Ceramic Bricks
Ceramic Bricks The following guidelines apply for all brick liners. 4. Rotate the anchor up and out of the way and slide the right hand side panel against the firebox side. 1. Inside the firebox, on the top of each side, release Rotate the anchor back down to hold the panel. - Page 17 Ceramic Logs 2. Place the rear log centering it side to side in the 5. Identify the right cross log; it has firebox. Position forward until it sits against the a hole under on of its end and it is sheet metal return behind the burner.
-
Page 18: Window Refitting
Window Refitting 1. To refit the window, hook its top part to the firebox’s opening frame. Make sure that the wider part of the window frame is at the bottom. 2. While you hold it, push in and turn the two top spring-loaded bolts a quarter turn to engage their pin. -
Page 19: Remote Control Handset Wall Holder Installation
Remote Control Handset Wall Holder Installation The remote control kit for this fireplace comes complete with a wall-mounted holder. This holder is not required in all installations but is provided as an optional feature for those customers who wish to mount the remote handset to the wall. -
Page 20: Owner's Information
Owner’s Information NOTE: This is a problem beyond Miles Industries’ CAUTION control and is not covered under warranty. Your fireplace becomes very hot when operating. • Clean the glass regularly as soon as you notice Avoid placing decorating objects sensitive to heat the buildup (white film). - Page 21 Owner’s Information Soot or dust can be brushed from the ceramic logs Batteries and firebox walls using a soft brush. Dust can also CAUTION be removed from the burner using a soft brush after DO NOT USE a screwdriver or other metallic object removing the ceramic logs.
-
Page 22: Remote Control Operation
Remote Control Operation Your fireplace remote control helps you get the comfort, convenience and aesthetics you want from your gas fireplace. The remote controls your fireplace in different ways. IMPORTANT: BEFORE YOU BEGIN, please note that on this system, the settings of time, temperature and automatic ON/OFF can only be programmed when the function display is flashing. - Page 23 Remote Control Operation Setting the flame Use this setting when you want a particular flame level. For instance, you want to watch flames burn at their highest level and you don’t mind if the room is too hot. 1. To raise the flame, press and hold the ▲ button until the flame gets to the desired level.
-
Page 24: Lighting Instructions
Lighting Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot, which must be lighted by hand. When lighting the pilot, follow these instructions exactly. -
Page 25: Options
Options Venting (required) Hearth Gate (optional) Approved venting accessories as per local codes. Hearth gates such as Kidco’s are available at retail stores carrying safety products for children. Inner Front (required) See your dealer for your choice of Inner Fronts. Outer Surrounds, Trims &... -
Page 26: Warranty
Warranty If you have a problem with this unit, please contact your dealer or supplier immediately. Under no circumstances should you attempt to service the unit in any way by yourself. The warranties in paragraphs 1 and 2 are provided only to the first purchaser/user of this unit, are not transferable and are subject to the conditions and limitations in paragraphs 3, 4 and 5. -
Page 27: Spare Parts
Spare Parts Part Part Code Description Code Description Number Number Exhaust Slide Assembly 4000127 Pipe Connector 220K891 Port Cover 4001820AH Thermocurrent Interruptor 4000202 Log Support 4001841 GV34 Valve w by-pass 125 4000056 Side Bricks Anchors (2) 4001283 Inlet Brass Connector 4000746 Top Mounting Bracket 4000136BY... - Page 28 Spare Parts...
- Page 29 Thank You ... For purchasing a Valor by Miles Industries. Your new radiant gas heater is a technical appliance that must be installed by a qualified dealer. Please circle where appropriate - ask your installer or your dealer if in doubt. The information provided will be used for customer records only.
- Page 30 Tape Shut Fold here Postage needed Miles Industries Ltd. 190 - 2255 Dollarton Highway North Vancouver, BC V7H 3B1 Canada Online Warranty registration at www.valorfireplaces.com Were you given all documentation and manuals for your product? Thank you for choosing a Valor Product...
