- Page 1 Set Up Guide • Guía de configuración • Guide de configuration Lifestyle 135 series IV ®...
-
Page 2: Important Safety Instructions
Please check your local building codes for the correct type of wire and cable required for in-wall installation. • Changes or modifications not expressly approved by Bose Corporation could void the user’s authority to operate this equipment. Important Safety Instructions 1. - Page 3 Bose Corporation hereby declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC and all other applicable EU directive requirements.
- Page 4 “5” is 2005 or 2015. Digits 2-4 are the month and date; “001” is January 1 and “365” is December 31. China Importer: Bose Electronics (Shanghai) Company Limited, Part C, Plan 9, No. 353 North Riying Road, China (Shanghai) Pilot Free Trade Zone...
-
Page 5: Table Of Contents
Contents Introduction About your Lifestyle SoundTouch™ system ..........® SoundTouch™ ..................... About your SoundTouch™ wireless adapter .......... Unpacking the System Carton contents ....................Accessories boxes ..................... Cables and power cords box ..............Essentials box ..................... Control console box ................... Setting Up the Soundbar Connecting the soundbar ................ -
Page 6: About Your Lifestyle ® Soundtouch™ System
Introduction About your Lifestyle SoundTouch™ system ® The Lifestyle SoundTouch system is elegant and easy-to-use, delivering su- ® ™ perior performance for both music and video. This guide provides step-by-step instructions for setting up your new system. Your new home entertainment system includes a soundbar, control console, Acoustimass module, SoundTouch wireless adapter and a universal remote... -
Page 7: Unpacking The System
Note: If part of the system is damaged, do not use it. Contact your authorized Bose dealer or Bose customer service. Refer to the contact sheet in the ® carton. -
Page 8: Essentials Box
Unpacking the System Essentials box SoundTouch series II ADAPTiQ audio calibration Operating guide ™ ® wireless adapter headset FM antenna IR emitter cable Stereo audio cable USB cable USB drive (for system Acoustimass module feet updating only) and Soundbar feet Control console box Power supply Remote control and... -
Page 9: Setting Up The Soundbar
Setting Up the Soundbar Connecting the soundbar The Lifestyle SoundTouch entertainment system uses the reflective surfaces of ® ™ your room to deliver wide, spacious sound. For best sound quality, the soundbar should not be placed inside a cabinet, or diagonally in a corner. To avoid wireless interference, keep other wireless equipment away from the sys- tem. - Page 10 Setting Up the Soundbar Insert the small end of the power cord into the Power connector. Note: Do not plug the power cord into an AC power outlet until instructed to do so. Power cord Arrange the cables as needed for your setup location. OPTIONAL: Secure cables under the clips in the channel running along the length of the soundbar and attach the extension feet (page 12).
- Page 11 Setting Up the Soundbar Turn the soundbar over and place it in front of your TV with the speaker grille facing into the room. English - 11...
-
Page 12: Attaching The Optional Extension Feet To The Soundbar
Wall mounting the soundbar You can mount the soundbar on a wall. To purchase the WB-135 Wall Mount Kit, contact your local Bose dealer or visit www.Bose.com CAUTION: Do not use any other hardware to mount the soundbar. 12 - English... -
Page 13: Setting Up The Control Console
Setting Up the Control Console Connecting the control console What you need: Power supply HIGH-SPEED Power cord Control console HDMI cable ™ Place the control console on a flat, stable surface near your TV. Control console Note: Until your system is completely installed, keep the control console positioned for easy access to the rear connector panel. - Page 14 Setting Up the Control Console Insert one end of the HIGH-SPEED HDMI cable into an HDMI IN connector ™ on your TV. If an HDMI cable is already connected to an HDMI connector on your TV, you can disconnect the other end and use this cable. Note: If you plan on viewing 3D content, use the supplied HIGH-SPEED HDMI cable.
- Page 15 Insert the soundbar’s audio input cable into the Audio OUT connector on the control console with the flat surface and arrow on the plug facing up. Note: Do not connect the audio input cable to a Bose link connector. Audio OUT Insert the power supply output cord into the Power connector.
-
Page 16: Connecting The Acoustimass Module
Setting Up the Acoustimass Module ® Connecting the Acoustimass module ® What you need: Rubber feet Power cord Acoustimass module CAUTION: Choose a stable and level surface for the Acoustimass module. Vibration can cause the module to move, particularly on smooth surfaces like marble, glass or highly polished wood. -
Page 17: Setting Up The Acoustimass Module
Setting Up the Acoustimass Module ® Place the Acoustimass module according to the following guidelines: ® • For best sound quality, stand the Acoustimass module on its feet along the same wall as your TV, or along any other wall in the front third of the room. •... -
Page 18: Starting Up The System
Starting Up the System What you need: SoundTouch series II ™ ADAPTiQ audio ® wireless adapter calibration headset Remote control and batteries USB cable Before you start: • Do not connect any devices to the control console until instructed by UNIFY ®... -
Page 19: Powering On The System
Starting Up the System Powering on the system Press the power button on the control console. Note: The system operates in a power saving mode when it is off to keep energy consumption low, so it may take several seconds to start. Status indicator Power button Check that the status indicator on the soundbar is off. -
Page 20: Completing Setup With Unify
® The UNIFY intelligent integration system guides you through the initial process of setting up your system. It guides you through choosing the right cables and inputs, and programming the Bose remote to operate your connected devices. ® Follow the instructions on your TV screen to complete the following: •... -
Page 21: Care And Maintenance
Refer to “Troubleshooting” in the operating guide. Contacting customer service For additional help using the system: • Visit SoundTouch.com • Contact Bose Customer Service. Refer to the contact sheet in the carton. ® English - 21... -
Page 22: Appendix: Using Unify
On your smartphone or tablet, download the SoundTouch controller app. ™ On your smartphone or tablet, download the SoundTouch controller app. ™ Bose SoundTouch ® controller app • iOS users: download from the App Store • Android users: download on the Google Play store ™... - Page 23 English - 23...
