The turntable motor is located on the bottom of the

microwave oven.

To remove the turntable motor:

Remove 8 Phillips-head screws from the bottom

of the microwave oven cabinet.

2. Disconnect the wiring harness to the turntable

motor.

3. Remove the 2 Phillips-head screws attaching

the turntable motor to the microwave oven and

remove the turntable motor.

Door Assembly

The door is available as a complete assembly or as

individual parts.

A microwave leakage test must be performed any

time a door is removed, replaced, disassembled, or

adjusted for any reason. The maximum leakage is 4

MW/CM

. (See

To remove the door, ﬁ rst remove the grill assembly.

Lift the door up and disengage from the hinge pins.

Disconnect

– 25 –
