SERVICE MANUAL

EP783/EP783S/EP783L/OPX5000/TX783L/TX783S
Date
Revise Version
2008.06.05
2008.08.20
2009.11.30
2010.02.22
Copyright February, 2010. All Rights Reserved P/N: 36.87F03G001
SI :
V1.0
Update Wireless Function "Hard-Reset" in Chapter 4
V2.0
Add Appendix A and Appendix B
Update test specifications in Chapter 4;
V3.0
Update FW upgrade method in Chapter 5;
V4.0
Modify CH4 "Defect specification table"
TSE:
Description
Initial Issue
Check:
Approved:
