Optoma EP783S RS232 Command Table
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Baud Rate : 9600
Data Bits: 8
Parity: None
Stop Bits: 1
Flow Control : None
UART16550 FIFO: Disable
Projector Return (Pass): P
Projector Return (Fail): F
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SEND to projector
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code
HEX Code
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX00 1
7E 30 30 30 30 20 31 0D
~XX00 2
7E 30 30 30 30 20 32 0D
~XX00 1 ~nnnn
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX01 1
7E 30 30 30 31 20 31 0D
~XX02 1
7E 30 30 30 32 20 31 0D
~XX02 2
7E 30 30 30 32 20 32 0D
~XX03 1
7E 30 30 30 33 20 31 0D
~XX03 2
7E 30 30 30 33 20 32 0D
~XX04 1
7E 30 30 30 34 20 31 0D
~XX04 2
7E 30 30 30 34 20 32 0D
~XX05 1
7E 30 30 30 35 20 31 0D
~XX06 1
7E 30 30 30 36 20 31 0D
~XX07 1
7E 30 30 30 37 20 31 0D
~XX08 1
7E 30 30 30 38 20 31 0D
~XX09 1
7E 30 30 30 39 20 31 0D
~XX10 1
7E 30 30 31 30 20 31 0D
~XX12 1
7E 30 30 31 32 20 31 0D
~XX12 2
7E 30 30 31 32 20 32 0D
~XX12 4
7E 30 30 31 32 20 34 0D
~XX12 5
7E 30 30 31 32 20 35 0D
~XX12 6
7E 30 30 31 32 20 36 0D
~XX12 7
7E 30 30 31 32 20 37 0D
~XX12 8
7E 30 30 31 32 20 38 0D
~XX12 9
7E 30 30 31 32 20 39 0D
~XX12 10
7E 30 30 31 32 20 31 30 0D
~XX12 11
7E 30 30 31 32 20 31 31 0D
~XX12 12
7E 30 30 31 32 20 31 32 0D
~XX12 13
7E 30 30 31 32 20 31 33 0D
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX20 1
7E 30 30 32 30 20 31 0D
~XX20 2
7E 30 30 32 30 20 32 0D
~XX20 3
7E 30 30 32 30 20 33 0D
~XX20 4
7E 30 30 32 30 20 34 0D
~XX20 5
7E 30 30 32 30 20 35 0D
~XX20 6
7E 30 30 32 30 20 36 0D
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX21 n
7E 30 30 32 31 20 a 0D
~XX22 n
7E 30 30 32 32 20 a 0D
~XX23 n
7E 30 30 32 33 20 a 0D
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX170 n
7E 30 30 31 37 30 20 a 0D
~XX171 n
7E 30 30 31 37 31 20 a 0D
~XX27 n
7E 30 30 32 37 20 a 0D
~XX172 n
7E 30 30 31 37 32 20 a 0D
~XX173 n
7E 30 30 31 37 33 20 a 0D
~XX28 n
7E 30 30 32 38 20 a 0D
~XX174 n
7E 30 30 31 37 34 20 a 0D
~XX175 n
7E 30 30 31 37 35 20 a 0D
~XX29 n
7E 30 30 32 39 20 a 0D
~XX176 n
7E 30 30 31 37 36 20 a 0D
~XX177 n
7E 30 30 31 37 37 20 a 0D
~XX30 n
7E 30 30 33 30 20 a 0D
~XX178 n
7E 30 30 31 37 38 20 a 0D
~XX179 n
7E 30 30 31 37 39 20 a 0D
~XX31 n
7E 30 30 33 31 20 a 0D
~XX180 n
7E 30 30 31 38 30 20 a 0D
~XX181 n
7E 30 30 31 38 31 20 a 0D
~XX32 n
7E 30 30 33 32 20 a 0D
~XX33 1
7E 30 30 33 33 20 a 0D
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX34 n
7E 30 30 33 34 20 a 0D
~XX35 1
7E 30 30 33 35 20 31 0D
~XX35 2
7E 30 30 33 35 20 32 0D
~XX35 3
7E 30 30 33 35 20 33 0D
~XX35 4
7E 30 30 33 35 20 34 0D
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX36 1
7E 30 30 33 36 20 31 0D
~XX36 2
7E 30 30 33 36 20 32 0D
~XX36 3
7E 30 30 33 36 20 33 0D
~XX37 1
7E 30 30 33 37 20 31 0D
~XX37 2
7E 30 30 33 37 20 32 0D
~XX37 3
7E 30 30 33 37 20 33 0D
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Function
Power ON
Power OFF
Power On with Password
Resync
AV Mute
On
Off
Mute
On
Off
Freeze
Unfreeze
Zoom Plus
Zoom Minus
Up (Pan under zoom)
Down (Pan under zoom)
Left (Pan under zoom)
Right (Pan under zoom)
Direct Source Selection
HDMI
DVI-D
BNC
VGA 1
VGA 2
VGA 1 SCART
VGA 1 Component
S-Video
Video
Wireless
VGA 2 SCART
VGA 2 Component
Display Mode
Presentation
Bright
Movie
sRGB
User 1
User 2
Brightness
Contrast
Sharpness
Color
Red Hue
Red Saturation
Red Gain
Green Hue
Green Saturation
Green Gain
Blue Hue
Blue Saturation
Blue Gain
Cyan Hue
Cyan Saturation
Cyan Gain
Yellow Hue
Yellow Saturation
Yellow Gain
Magenta Hue
Magenta Saturation
Magenta Gain
Reset
White Peaking
Degamma
Film
Video
Graphics
PC
Color Temp.
Warm
Medium
Cold
Color Space
Auto
RGB
YUV
XX=01-99, projector's ID, XX=00 is for all projectors
Description
n= -50 (a= 2D 35 30) ~ +50 (a= 35 30)
n= -50 (a= 2D 35 30) ~ +50 (a= 35 30)
n= -50 (a= 2D 35 30) ~ +50 (a= 35 30)
n= -100 (a= 2D 30 30) ~ 100 (a= 31 30 30)
n= 0 (a= 30) ~ 199 (a= 31 39 39)
n= 0 (a= 30) ~ 199 (a= 31 39 39)
n= -100 (a= 2D 30 30) ~ 100 (a= 31 30 30)
n= 0 (a= 30) ~ 199 (a= 31 39 39)
n= 0 (a= 30) ~ 199 (a= 31 39 39)
n= -100 (a= 2D 30 30) ~ 100 (a= 31 30 30)
n= 0 (a= 30) ~ 199 (a= 31 39 39)
n= 0 (a= 30) ~ 199 (a= 31 39 39)
n= -100 (a= 2D 30 30) ~ 100 (a= 31 30 30)
n= 0 (a= 30) ~ 199 (a= 31 39 39)
n= 0 (a= 30) ~ 199 (a= 31 39 39)
n= -100 (a= 2D 30 30) ~ 100 (a= 31 30 30)
n= 0 (a= 30) ~ 199 (a= 31 39 39)
n= 0 (a= 30) ~ 199 (a= 31 39 39)
n= -100 (a= 2D 30 30) ~ 100 (a= 31 30 30)
n= 0 (a= 30) ~ 199 (a= 31 39 39)
n= 0 (a= 30) ~ 199 (a= 31 39 39)
n= 0 (a= 30) ~ 10 (a= 31 30)
