HRC216HXA
LAWN MOWER
Before operating the mower for the first time, please read this
Owner's Manual. Even if you have operated other mowers,
take time to become familiar with how this mower works and
practice in a safe area until you build up your skills.
7
Maintenance Schedule
16
Operating the Controls
21
Oil Change
Spark Plug
10
10
11
12
12
12
13
13
14
14
15
16
16
16
16
Dealer Locator Information
16
16
16
Click to Save As
11
9
13
14
17
17
17
17
17
18
18
18
18
19
19
20
21
21
21
21
21
22
23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HRC216HXA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Honda HRC216HXA

Summary of Contents for Honda HRC216HXA

  • Page 1: Table Of Contents

    Storage Location Honda Publications Stopping the Engine Removing From Storage DISTRIBUTOR’S LIMITED WARRANTY EMISSION SYSTEM WARRANTY QUESTIONS? Contact your Honda dealer. There is a dealer locater at powerequipment.honda.com 00X31VK6 7300 © 2014 American Honda Motor Co., Inc. All Rights Reserved...

  • Page 2: Important Message To Parents

    Important Message to Parents WELCOME The safety of your children is very important to Honda. Lawn mowers are tools, not toys. As with any equipment, bad judgments can result in serious injuries. Your child must be big enough, strong enough, and...

  • Page 3: Parts And Controls

    BLADE CONTROL (P. 9) following list. Contact the authorized Honda dealer from whom you LEVER purchased the mower if any of the loose parts shown are not included with your mower.

  • Page 4: Adjust The Handlebar

    Adjust the Handlebar 7. Pry open the right side handle support hanger, and place it over the right handle above the starter rope guide. Squeeze the ends together. Make sure the ribs are facing out, as shown. 1. Pry open the right side handle support hanger, and place it over the right handle above the starter rope guide.

  • Page 5: Add Engine Oil

    After filling the engine with oil, screw the filler/cap dipstick in and Please take a few minutes and register your purchase with Honda. remove the hang tag near the recoil starter grip that says “The engine You can register by completing and mailing the registration card has no oil.”...

  • Page 6: Before Each Operation

    If the rear shield is excessively worn, Your safety is your responsibility. A little time spent in preparation will have it replaced by your authorized Honda servicing dealer. significantly reduce your risk of injury.

  • Page 7: Add Fuel

    Check the Oil Level Installation GRASS DISCHARGE 1. Raise the discharge 1. Unscrew and remove the filler GUARD guard and hook the cap/dipstick and wipe it clean. grass bag onto the 2. Insert and remove the dipstick mower deck as shown. without screwing it into the Clean any grass filler neck.

  • Page 8: Operation

    1. Remove the fuel tank cap.  WARNING 2. Add fuel to the bottom The blades are sharp and spin at high speed. A spinning of the red fuel level blade can cut you severely and can amputate fingers and gauge in the neck of the toes.

  • Page 9: Operating The Controls

    Avoid Obstacles Always release the blade control lever before starting the engine to prevent the blades from turning. Gravel, loose stones, and landscaping material can be picked up by the mower and thrown many feet with enough force to cause serious personal injury and/or property damage.

  • Page 10: Starting The Engine

    To ensure throttle lever at FAST to mow or at SLOW to idle. the best quality and reliability, use only new, Honda Genuine parts or Stopping the Engine their equivalents for repair and replacement.

  • Page 11: Maintenance Schedule

    (2) Service more frequently when used in dusty areas. (3) These items should be serviced by an authorized Honda servicing dealer unless you have the proper tools and are mechanically proficient. Refer to the Honda shop manual for service procedures. See “Honda Publications” on...

  • Page 12: Blade Inspection

    AND WASHER [2] 4. Tighten the blade bolts with a torque wrench to the specified If a blade is bent, take the lawn mower to an authorized Honda torque. Use a wooden block to prevent the blades from turning servicing dealer for inspection.

  • Page 13: Air Filter

    We recommend the use of a Honda Genuine air filter to ensure it To reduce the chance of scratching the side of the mower deck or seals and performs as designed. Using a non-Honda air filter can...

  • Page 14: Spark Plug

    Honda NOTICE servicing dealer. See page 21 for part numbers. Excess oil will restrict air flow through the foam element and may transfer to the paper element, soaking and clogging it. 1. Allow the engine to cool and disconnect the spark plug cap.

  • Page 15: Drive Clutch Cable Adjustment

    Push the choke arm with your finger to verify that it has moved as far as it will go. If the choke arm does not move all the way to its stop in either direction, take the mower to an authorized Honda servicing dealer. Throttle cable...

  • Page 16: Cleaning

    Cleaning TRANSPORTING Mower Deck Before washing the underside of the mower deck, stop the engine and If the engine has been running, allow it to cool before loading the turn the fuel valve to the OFF position. Rest the mower on its right mower on the transport vehicle.

  • Page 17: Troubleshooting

    (page Blades bent, damaged, or Take the mower to an Bad fuel; mower stored without Refuel with fresh gasoline unbalanced by improper authorized Honda servicing treating gasoline, or refueled with (page sharpening dealer for repair. bad gasoline Mechanical damage, such as a...

  • Page 18: Technical Information

    The following instructions and procedures must be followed in order to keep the emissions from your Honda engine within the emissions standards. MODEL NAME AND Tampering and Altering...

  • Page 19: Air Index

    Air Index Transmission Design and Performance An Air Index Information hang tag/label is applied to engines certified Transmission Type Hydrostatic, fluid drive, infinitely to an emission durability time period in accordance with the variable speeds requirements of the California Air Resources Board. Maximum Mower Ground 1.78 m/s (3.98 mph) The bar graph is intended to provide you, our customer, the ability to...

  • Page 20: Avoiding Fuel-Related Problems

    AVOIDING FUEL-RELATED PROBLEMS When properly maintained, your Honda powered product should provide years of trouble-free operation. This includes the fuel system. However, gasoline can quickly deteriorate (in as little as 30 days) causing starting or running problems and, in some cases, damage to the fuel system.

  • Page 21: Dealer Locator Information

    The information and specifications included in this publication were in effect at the time of approval for printing. American Honda Motor Co., Service Items Inc. reserves the right, however, to discontinue or change specifications or design at any time without notice and without incurring any obligation whatever.

  • Page 22: Distributor's Limited Warranty

    Installing parts and accessories on non-Honda products or engines voids this warranty. American Honda will repair or replace, at its option, any part that is proven to be defective in material or workmanship under normal use during the applicable You must be the first retail purchaser.

  • Page 23: Emission System Warranty

    United States and its territories. Honda Canada Inc. Honda dealer determines it is defective or causes a failure of a warranted part, provides the emission warranty for engines in the 13 provinces and territories of your claim for repair of your engine may be denied.
  • Page 24 HPE.2014.11 PRINTED IN U.S.A.
