- Page 1 FBT elettronica SpA Via Paolo Soprani 1 - Zona Ind.le Squartabue - 62019 RECANATI - ITALY Tel. 071 750591 - Fax. 071 7505920 - email: info@fbt.it - www.fbt.it...
- Page 2 ARCHON THE ARCHON SERIES WARNINGS DESCRIPTION 3/4/5/6/7/8/9/10 ACCESSORIES 11/12/13/14 INSTALLATION - warnings INSTALLATION MODES 16/17/18/19 CONNECTIONS 20/21/22/23/24/25 ROTATABLE HORN GLOSSARY...
- Page 3 THE ARCHON SERIES The new ARCHON series includes a vast range of 2-way passive speakers for permanent installations: three models with possibility of full-range or bi-amp configuration; three compact models with full-range configuration, two 2x8” and 2x15” subwoofers. Beyond the classic black and white, availability of a vast range of colours and finishes: gloss, matt, rough texture, etc.
- Page 5 > 4 x Euroblock speaker terminals > Multiple M5 threaded rigging points > Acoustically transparent steel grille and antidust protection cloth > New FBT rotatable logo badge following vertical or horizontal installation > Optional mounting hardware > 50W optional line transformer...
- Page 6 4 x Euroblock speaker terminals > Multiple M5 threaded rigging points > Acoustically transparent steel grille and antidust protection cloth > New FBT rotatable logo badge following vertical or horizontal installation > Optional mounting hardware > 100W optional line transformer...
- Page 7 4 x Euroblock speaker terminals > Multiple M5 threaded rigging points > Acoustically transparent steel grille and antidust protection cloth > New FBT rotatable logo badge following vertical or horizontal installation > Optional mounting hardware > 100W optional line transformer...
- Page 8 > 2 x metal flange threads for "U" bracket wall mount > Acoustically transparent steel grille and antidust protection cloth > Rear pocket handle > 35mm top hat for speaker stand > New FBT rotatable logo > Optional mounting hardware > 200W optional line transformer 2 way...
- Page 9 > 2 x metal flange threads for "U" bracket wall mount > Acoustically transparent steel grille and antidust protection cloth > Rear pocket handle > 35mm top hat for speaker stand > New FBT rotatable logo > Optional mounting hardware > 300W optional line transformer 2 way...
- Page 10 > 2 x metal flange threads for "U" bracket wall mount > Acoustically transparent steel grille and antidust protection cloth > Rear pocket handle > 35mm top hat for speaker stand > New FBT rotatable logo > Optional mounting hardware > 300W optional line transformer 2 way...
- Page 11 ARCHON DESCRIPTION 208S 18.89 inch THE ARCHON 208S IS NOT EQUIPPED WITH INTERNAL PASSIVE CROSSOVER; A CONNECTION TO THE POWER UNIT WITHOUT PROCESSOR WILL DAMAGE THE SPEAKERS. 21.65 inch > Passive subwoofer with bass-reflex enclosure > 2 x 8" custom made high excursion woofer >...
- Page 12 ARCHON DESCRIPTION 215S 25.19 inch THE ARCHON 215S IS NOT EQUIPPED WITH INTERNAL PASSIVE CROSSOVER; A CONNECTION TO THE POWER UNIT WITHOUT 35.43 inch PROCESSOR WILL DAMAGE THE SPEAKERS. > Passive subwoofer with bass-reflex enclosure > 2 x 15" custom made high excursion woofer >...
- Page 13 > Installation with adjustable wall support ( 105 / 106 / 108 ) > Simple stack installation ( 208S / 215S ) The ARCHON speakers use only with FBT mount for wall installation. USE WITH OTHER MOUNTS IS CAPABLE OF RESULTING IN INSTABILITY CAUSING POSSIBLE INJURY.
- Page 14 ARCHON ACCESSORIES 14.68 inch AC-U112H 5.37 inch 5.37 inch 26.29 inch AC-U112V 11.18 inch 11.18 inch...
- Page 15 ARCHON ACCESSORIES 17.4 inch AC-U115H 6.73 inch 6.73 inch 29.4 inch AC-U115V 12.73 inch 12.73 inch...
- Page 16 ARCHON 105 / 106 / 108 ACCESSORIES AC-W568 2.36 inch ARCHON 208S ACCESSORIES AC-W208 BRACKET ON SPEAKER WALL BRACKET 7 inch 7 inch...
-
Page 18: Vertical Installation
VERTICAL INSTALLATION... -
Page 20: Installation Modes
ARCHON 208S INSTALLATION MODES SUSPENDED SUBWOOFER INSTALLATION BRACKET ON SPEAKER WALL BRACKET > Carefully choose the area where speakers will be installed, making sure that the structure can support cabinet's weight. > Remove the 4 speaker's feet and fix the two brackets using the 4 M8 screws provided. -
Page 21: Stack Installation
ARCHON INSTALLATION MODES INSTALLATION ON TRIPOD STAND > Make sure that the stand can bear speaker's weight > Place the stand on a flat and antislip surface > Widen stand base as much as possible to increase its stability STACK INSTALLATION Subwoofer on the ground and the relevant satellite on it. - Page 23 ARCHON 105 / 106 / 108 CONNECTIONS The ARCHON series 105 / 106 / 108 models can be setup in constant impedance or constant voltage mode thanks to an optional line transformer. CONSTANT VOLTAGE LINE Connect a conductor from the speaker terminal marked with “COM” to the 100V line in the amplifier terminal marked with “-“, “0”, “COM”.
- Page 24 ARCHON 105 / 106 / 108 CONNECTIONS CONSTANT VOLTAGE LINE ARCHON POWER AMP. 200W HI LO NC NC 8Ω ARCHON ARCHON ARCHON ARCHON HI LO HI LO HI LO HI LO CONSTANT IMPEDANCE CONNECTION ARCHON IN CH1 IN CH2 POWER AMP.
- Page 25 ARCHON 110 / 112 / 115 CONNECTIONS The ARCHON series 110 / 112 / 115 models can be setup in FULL-RANGE or BI- AMP mode. For work mode selection refer to page 51. The FULL-RANGE mode allows connection through Speakon connectors (1+ / 1-) or terminal board with constant impedance (8Ohm) and 100V voltage.
-
Page 26: Operating Mode Selector
All the drivers are tested with a crest factor of 2; to obtain this value, equalling a 6dB dynamics between average and peak value, an amplifier with twice the RMS power indicated in the table shall be used. The amplifier recommended by FBT permits obtaining at least a 6dB dynamics in high SPL applications to keep a high sound quality. - Page 27 ARCHON 208S / 215S CONNECTIONS THE ARCHON 208S / 215S ARE NOT EQUIPPED WITH INTERNAL PASSIVE CROSSOVER; A CONNECTION TO THE POWER UNIT WITHOUT PROCESSOR WILL DAMAGE THE SPEAKERS. IN CH2 OUT 2 STEREO OUT CONNECTION ARCHON 208S NEGATIVE OUT...
-
Page 28: Rotatable Horn
110 / 112 / 115 ROTATABLE HORN The ARCHON series 110 / 112 / 115 models feature a constant directivity rotatable horn. The constant directivity horn permits getting a response whose frequency is almost constant in every direction covered by horn operation and a balanced sound timbre emission over the whole coverage angle. - Page 29 ARCHON GLOSSARY AMPLIFIER CLASS Power amplifiers are mainly classified according to the type of output stage. Such classification is based on how long output devices remain active during each cycle. The most common classes of professional sound amplifiers are: AB, AB+B, D, G, H.
