Owner's Manual
UHD 4Kx2K HDMI Splitters
Models: B118-002-UHD, B118-004-UHD,
B118-004-UHD-WM, B118-008-UHD
Product Features
Package Contents
Installation
Troubleshooting
Warranty & Product Registration
1111 W. 35th Street, Chicago, IL 60609 • www.tripplite.com/support
Copyright © 2014 Tripp Lite. All rights reserved.
1
2
3
4
5
6
12/18/2014 4:36:37 PM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B118-002-UHD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tripp Lite B118-002-UHD

Summary of Contents for Tripp Lite B118-002-UHD

  • Page 1 UHD 4Kx2K HDMI Splitters Models: B118-002-UHD, B118-004-UHD, B118-004-UHD-WM, B118-008-UHD Product Features Package Contents Installation Troubleshooting Warranty & Product Registration 1111 W. 35th Street, Chicago, IL 60609 • www.tripplite.com/support Copyright © 2014 Tripp Lite. All rights reserved. 14-12-191-93335C.indd 1 12/18/2014 4:36:37 PM...
  • Page 2 • HDCP and EDID compatible • Plug and play; no software or drivers required • The B118-002-UHD features a built-in cable to connect to the source • The B118-004-UHD-WM features a versatile design that allows for both desktop and wall-mount use • Supports Lip Sync pass-through...
  • Page 3 Package Contents • UHD 4Kx2K HDMI Splitter • External Power Supply • B118-002-UHD (Input: 100-240V, 50/60Hz, 0.5A Output: 5V, 2A) • B118-004-UHD (Input: 100-240V, 50/60Hz, 1.5A Output: 5V, 3A) • B118-004-UHD-WM (Input: 100-240V, 50/60Hz, 1.5A Output: 5V, 3A) • B118-008-UHD (Input: 100-240V, 50/60Hz, 1.5A Output: 5V, 4A) • Mounting hardware (B118-004-UHD-WM only)
  • Page 4 Installation Source B118-008-UHD Notes: • The maximum distances referenced in these instructions have been tested at a video resolution of UHD 4Kx2K 3840 x 2160 @ 24Hz and 30Hz with 36-bit (12-bits per channel) Deep Color using 28AWG HDMI cables. Longer distances between the splitter and connected monitors are achievable using 24AWG HDMI cables.
  • Page 5 Was the power to the connected devices turned off prior to installation? If not, restart them. What resolution are you trying to reach? Tripp Lite’s UHD 4Kx2K HDMI splitters are tested to support up to 3840 x 2160 @ 24Hz and 30Hz video resolution, at 36-bit Deep Color (12-bits per channel).
  • Page 6 TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center.
  • Page 7 • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user’s authority to operate this equipment. PRODUCT REGISTRATION Visit www.tripplite.com/warranty today to register your new Tripp Lite product.
  • Page 8 1111 W. 35th Street, Chicago, IL 60609 • www.tripplite.com/support 14-12-191 93-335C_RevC 14-12-191-93335C.indd 8 12/18/2014 4:36:40 PM...
