Insignia NS-PCH5420/NS-PCH5420-C Quick Setup Manual

Quick Setup Guide |
PACKAGE CONTENTS
• High Speed 4-port USB 2.0 Hub
• Quick Setup Guide
SYSTEM REQUIREMENTS
• Computer with a USB port
• Latest version of Windows ®8, Windows® 7, Windows
Vista®, or Windows® XP; or Mac OS X 10.4 or later
• Minimum free disk space: 600MB recommended
FEATURES
INSTALLING YOUR HUB
• Complies with Universal Serial Bus 2.0 Specification
Note: When you connect your hub to a computer, the
• Backwards compatible with USB 1.1 devices
computer detects your hub and automatically installs it.
• Supports transfer rates of up to 480Mbps
1 Connect the USB cable attached to the hub to an
• Adds four USB 2.0 ports to your USB 2.0 enabled
open USB port on your computer.
computer
The driver is installed automatically and you can
• Easy-storage attached USB cable
start to use it immediately.
• Blue LED power indicator
• Supports hot-swappable and Plug & Play capability
• Supports over-current protection at USB host port
Before using your new product, please read these instructions to prevent any damage.
NS-PCH5420/NS-PCH5420-C
2 Plug your USB devices into the hub.
4 Port USB 2.0 Travel Hub
Downstream ports (2)
not shown
Computer connection
cable (shown stowed)
Note: Do not disconnect from your computer or USB device
during data transfer. Doing so may corrupt your data or
LED
damage your devices.
Downstream ports
(to devices)
LEGAL NOTICES
FCC Caution
Changes or modifications not expressly approved by the part
responsible for compliance could void the user's authority to
operate the equipment.
FCC Statement
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
CONTENU DE L'EMBALLAGE
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and • Concentrateur USB 2.0 à 4 ports à haut débit
receiver.
• Guide d'installation rapide
—Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
CONFIGURATION SYSTÈME REQUISE
—Consult the dealer or an experienced radio/TV technician
for help.
• Ordinateur avec un port USB
This device complies with part 15 of the FCC Rules. Operation
• Version la plus récente de Windows
is subject to the following two conditions: (1) This device may
Windows Vista
not cause harmful interference, and (2) this device must
ou plus récent
accept any interference received, including interference that
• Espace disque minimum
may cause undesired operation.
ICES Statement requis : 600 Mo sont recommandés
CAN ICES-3 (B)/NMB-3 (B)
CARACTÉRISTIQUES
ONE-YEAR LIMITED WARRANTY
• En conformité avec la technologie USB 2.0
Visit www.insigniaproducts.com for details.
• Rétrocompatible avec les appareils USB 1.1
• Il offre un débit de transfert de données pouvant
CONTACT INSIGNIA:
atteindre 480 Mbits/s.
For customer service, call 877-467-4289 (U.S. and • Ajoute quatre ports USB 2.0 à un ordinateur à ports
Canada) or 01-800-926-3000 (Mexico) USB 2.0.
www.insigniaproducts.com • Câble USB à rangement pratique
• Témoin DEL d'alimentation bleu.
• Remplacement à chaud et prêt à l'emploi
INSIGNIA is a trademark of Best Buy and its affiliated companies.
Registered in some countries.
• Protection contre les surintensités au niveau du port
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A. USB hôte
©2014 Best Buy. All rights reserved.
Made in China
Avant l'utilisation de ce produit neuf, lire ces instructions afin d'éviter tout dommage.
Guide d'installation rapide |
NS-PCH5420/NS-PCH5420-C
Concentrateur de voyage USB 2.0 à 4 ports
Ports USB
descendants (2) non illustré
MD 8, Windows MD 7,
MD ou Windows MD XP ou Mac OS X 10.4
DEL
INSTALLATION DU CONCENTRATEUR
Remarque: Dès que le concentrateur est connecté à
l'ordinateur, celui-ci le détecte et l'installe automatiquement.
1 Connecter le câble USB fixé au concentrateur à un
port USB disponible de l'ordinateur.
Le pilote est installé automatiquement et il peut
être utilisé immédiatement.
Câble de connexion
à un ordinateur
(illustré rangé)
Ports descendants
(vers les périphériques)
