QUICK SETUP GUIDE
3-Port
HDMI Switch
NS-HZ335 / NS-HZ335-C
PACKAGE CONTENTS
• 3-Port HDMI switch
• Power adapter (Micro USB)
• Quick Setup Guide
Back view
HDMI output
Power port
HDMI inputs
Before using your new product, please read these instructions to prevent any damage.
FEATURES
• HDMI® 3D & 4K video format supported
• HDMI® 2.0 / HDCP 2.2 compliant
• DTS-HD®, Dolby® TrueHD lossless compressed
digital audio compliant
• Plug-and-Play, installs in seconds
• Connect up to three HDMI sources using only one
HDMI port on your TV
• Supports full 4K HDR signals up to 18 Gbps
• Push-button selection for easily changing the input
Note: HDMI cable(s) not included
Your 3-Port HDMI Switch supports the latest 4K video
and next-generation audio signals.
Note: In the unlikely event that a feature is not supported,
neither the picture nor the sound quality would be
degraded.
Top view
Power adapter
SETTING UP YOUR SWITCH
1 Connect HDMI cables (not included) from your
source devices to the switch's INPUT ports.
2 Connect an HDMI cable from your TV (or projector)
to the switch's OUTPUT port.
3 Connect the power adapter from the DC 5V port to
SELECT
a power outlet. The power LED and an input LED
light up.
Select
button
Satellite
Game
receiver
console
DVD or
Blu-ray
HDTV
player
or 3D TV
HDMI
HDMI
cable
cable
HDMI
HDMI
cable
cable
