Usb type-c travel hub

Advertisement

Quick Links

PACKAGE CONTENTS
• USB Type-C/A Hub
• Built-in USB cable
• Quick Setup Guide
SYSTEM REQUIREMENTS
• Computer with a Type-C USB port
Note: USB 3.0 is backward compatible with USB 2.0 and
1.1. However, data transfer speed will be limited to the
speed of the slowest port used.
• Windows® 10, Windows® 8.1, Windows® 8,
Windows® 7, Mac OS 10.X or higher , Chrome OS,
Linux , or Kernel 2.4.1 or above.
FEATURES
• One Type-C USB connector
• One Type C USB 3.1 data transfer and power
delivery port (up to 60W).
• One Type C USB 3.1 port (data only)
• Two Type-A USB 3.1 ports
• Backward compatible with USB 1.1 and USB 2.0 devices
Note: The first Type-C USB port can transfer data at
5Gbps and pass through power at 60W at the same
time. So you can use the USB ports at the same time
as you charge devices.
Before using your new product, please read these instructions to prevent any damage.
Quick Setup Guide |
Top view
Cable
Type-C
USB connector
Type-C 3.1 USB port
(for power delivery
and data transfer)
Type-C 3.1
USB port
NS-PHU37PD-BK / NS-PHU37PD-BK-C
INSTALLING YOUR HUB
• Plug the USB Type-C connector to the USB Type-C
port on your computer.
• To install USB peripherals, plug the devices into
USB 3.1
the USB HUB.
Type-A
• To remove USB peripherals, unplug the devices
port
from the USB HUB.
USB 3.1
Type-A
• To remove the USB HUB, unplug the USB
port
connector from your computer.
USB Type-C Travel Hub
USB Type-C connector
Type C
Charger
