OpTIONaL ExTRa KITs
• Horizontal Flue Terminal (1000mm long)
• Horizontal Flue Terminal (600mm long)
•
Telescopic Flue Kit - B pack
•
Flue Extension Ducts (1000mm long)
26-up to 9m
33-up to 8m
38-up to 6m
•
Flue Finishing Kit
•
90 o Elbow Kit (maximum per installation)
26-up to 6 elbows
33-up to 6 elbows
38-up to 4 elbows
•
o
45 Elbow Kit (maximum per installation)
26-up to 6 elbows
33-up to 6 elbows
38-up to 4 elbows
• Roof Flue Kit (to a maximum of 7.5m)
•
Concentric Flue screw Retaining Kit
•
powered Vertical Flue Kit (5m primary and 17m secondary
is a typical maximum length. For alternative details refer to
Powered Vertical Instructions)
• High Level Flue Outlet Kit
• Adjustable Flue Support Bracket
• Flue Deflector Kit
• Balcony Flue Kit
• Raised Horizontal Flue Outlet Kit
•
Weather Collar
• Weather Compensation Kit
• Stand-Off Kit
• Stand-Off Kit (inc. pipes)
• Pre-Piping Frame Kit
• Condensate Pump Kit
• DHW Expansion Vessel Kit
• Security Fixing Kit
• PRV Wall Outlet Kit
• Pressure Gauge Extension Kit
• Mechanical Timer (24 hr) Kit
• Electronic Timer (7 day) kit
• RF Mechanical Programmable Room Thermostat (24 hr)
kit
• RF Electronic Programmable Room Thermostat (7 day)
kit
• RF Mechanical Timer & Room Thermostat Kit
Ideal Logic Code Combi ES -
gENERaL
Installation and Servicing
saFETy
Current gas safety (installation and use) regulations or rules
in force:
The appliance is suitable only for installation in GB and IE and
should be installed in accordance with the rules in force.
In GB, the installation must be carried out by a Gas Safe
Registered Engineer. It must be carried out in accordance with
the relevant requirements of the:
• Gas Safety (Installation and Use) Regulations
• The appropriate Building Regulations either The Building
Regulations, The Building Regulations (Scotland), Building
Regulations (Northern Ireland).
• The Water Fittings Regulations or Water byelaws in Scotland.
• The Current I.E.E. Wiring Regulations.
Where no specific instructions are given, reference should be
made to the relevant British Standard Code of Practice.
In IE, the installation must be carried out by a Registered Gas
Installer (RGII) and installed in accordance with the current edition
of I.S.813 "Domestic Gas Installations", the current Building
Regulations and reference should be made to the current ETCI
rules for electrical installation.
Detailed recommendations are contained in the following British
Standard Codes of Practice:
Bs. 5440:1 Flues (for gas appliances of rated input not
exceeding 70 kW).
Bs. 5440:2 Ventilation (for gas appliances of rated input not
exceeding 70 kW).
BsEN. 12828:2003 Heating Systems in buildings: Design for
water based heating systems.
Heating Systems in buildings: Method for
BsEN 12831:2003
calculation of the design heat load.
Heating Systems in buildings: Installation
BsEN 14336:2004
and commissioning of water based heating
systems.
Bs. 5546 Installation of gas hot water supplies for domestic
purposes (2nd Family Gases)
Installation of gas fired hot water boilers of rated
Bs. 6798
input not exceeding 70 kW.
Low pressure installation pipes.
Bs. 6891
health & safety Document No. 635.
The Electricity at Work Regulations, 1989.
The manufacturer's notes must NOT be taken, in any way, as
overriding statutory obligations.
IMpORTaNT. These appliances are CE certificated for safety
and performance. It is, therefore, important that no external
control devices, e.g. flue dampers, economisers etc., are
directly connected to these appliances unless covered by
these Installation and Servicing Instructions or as otherwise
recommended by Ideal stelrad group in writing. If in doubt
please enquire.
Any direct connection of a control device not approved by
Ideal stelrad group could invalidate the certification and the
normal appliance warranty. It could also infringe the Gas Safety
Regulations and the above regulations.
saFE haNDLINg OF sUBsT aNCEs
No asbestos, mercury or CFCs are included in any part of the
boiler or its manufacture.
