Summary of Contents for JMC ANALOG/DVI2SDI/HDMI
-
Page 1: User Manual
ANALOG/DVI2SDI/HDMI User Manual Rev1.0 JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... -
Page 2: Table Of Contents
Feature ................... 3 Front Panel ................4 Rear Panel ................4 Side Panel ................5 DipSwitch/LED Control ..............6 Installation ................12 Specifications ................13 Firmware Upload ..............14 Appendix Table A ..............14 JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... -
Page 3: Feature
Firmware is upgradable in the field using the integrated USB port The converter is Plug-and-Play Support DVI-D, DVI-A, Component, CVBS and S-Video Input0 Support Embedded audio and stereo audio( L/R Audio ) JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... -
Page 4: Front Panel
Power Jack The Power adapter plug into here Rear Panel Component Function Phone Jack From you Audio Device plug into this port Component/CVBS/S-Video From your YPbPr/CVBS/S-Video Device plug Input Port into this port JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... -
Page 5: Side Panel
From your DVI-D/DIV-A Device plug into this DVI-D/DVI-A Input Port port Side Panel Component Function USB Port Upgrade firmware/Control Box From PC JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... -
Page 6: Dipswitch/Led Control
(Embedded audio/L/R Audio) Output format Control Box to switch Output Format. Input Source: VPC-MX1 Box can choose one of three standard inputSource by DipSwitch. Input Source Dipswitch Indicates DVI-D(HDMI) DVI-A(VGA) YPbPr JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... - Page 7 VPC-MX1 Box can be select audio source from L/R Audio. Resolution Dipswitch Indicates Internal (Default) L/R Audio Output Format: VPC-MX1box can be select 16 of kinds output format. Resolution Dipswitch Indicates Resolution 1920x1080p60 1920x1080i60 1920x1080p59 1920x1080i59 1920x1080p50 1920x1080i50 1920x1080p30 1280x720p60 JMC Systems Engineering AB www.jmc.se +46-8-82 82 70...
- Page 8 DVI-A(VGA) The LED is indicate DVI-A Signal indicate The LEDs is indicate YPbPr Signal YPbPr indicate CVBS The LED is indicate CVBS Signal indicate The LEDs is indicate S-Video Signal S-Video indicate JMC Systems Engineering AB www.jmc.se +46-8-82 82 70...
- Page 9 DVI-D + L/R Audio DVI-D DVI-A YPbPr Cvbs S-Video ● ○ ○ ○ ○ Locked ● ○ ○ ○ ○ Un-locked ●(Blinking) ○ ○ ○ ○ MicroVision 2. DVI-A+ L/R Audio: DVI-A + L/R Audio JMC Systems Engineering AB www.jmc.se +46-8-82 82 70...
- Page 10 3. YPbPr + L/R Audio: YPbPr + L/R Audio DVI-D DVI-A YPbPr Cvbs S-Video Locked ○ ○ ● ○ ○ ○ ○ ● ○ ○ Un-locked 4. Composite (CVBS) + L/R Audio: JMC Systems Engineering AB www.jmc.se +46-8-82 82 70...
- Page 11 ○ ○ ○ ●(Blinking) ○ MicroVision 5. S-VIDEO + L/R Audio Composite(CVBS) + L/R Audio DVI-D DVI-A YPbPr Cvbs S-Video ○ ○ ○ ○ ● Locked ○ ○ ○ ○ ● Un-locked JMC Systems Engineering AB www.jmc.se +46-8-82 82 70...
-
Page 12: Installation
MULTI2SDI-PRO installation consists of the following: 1. Disconnect +12DC adaptor to converter. 2. Connect Video Source to the Input Connector. 3. Connect Display Equipment to the output’s connector 4. Connect the +12DC adaptor to the converter. JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... -
Page 13: Specifications
1 x Phone Jack 3G 75 Ω inter-locked socket BNC Connector Dipswitch Output Format/Audio Source/Input Source Dimension L:153mm x W:63.3mm xH:26mm Power Source Power Adapter: AC 100 ~ 240 V/DC (+9 ~ 15 V) JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... -
Page 14: Firmware Upload
Open Upload Firmware Program tools.exe and connect box to PC by USB Cable. Step 2. Plug and un-plug “DC adapter” to power on/off the converter box (the connection check status will be changed to “Connect”) JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... - Page 15 Step 4. Please click “Start’ Button to proceed with new firmware programming. The PASS message will appear when the procedures finished. Step 5. Close Upload Firmware Program tools JMC Systems Engineering AB www.jmc.se +46-8-82 82 70...
-
Page 16: Appendix Table A
1360x768p60 1366x768p50 1366x768p60 1400x1050p50 1400x1050p59 1400x1050p60 1400x1050p75 1440x900p60 1440x900p75 1440x900p85 1600x1200p50 1600x1200p59 1600x1200p60 1600x1200pRB 1680x1050pRB 1680x1050p60 1920x1200pRB 2048x1052p60 2048x1080p50 2048x1080p59 2048x1080p60 Support Output Format: HDMI Mode 720x480 i60 720x480 i59.94 720x576 i50 JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... - Page 17 1280x720 p60 1280x720 p59.94 1280x720 p50 1920x1080 i60 1920x1080 i59.94 1920x1080 i50 1920x1080 p60 1920x1080 p59.94 1920x1080 p50 1920x1080 p30 1920x1080 p29.97 1920x1080 p25 1920 x 1080 p24 1920 x 1080 p23.98 JMC Systems Engineering AB www.jmc.se +46-8-82 82 70...
