Page 1: User Manual
Multi2SDI Scaling User Manual V1.1 JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... -
Page 2: Table Of Contents
Front Panel ................4 Rear Panel ................4 Top Panel ................. 5 Side Panel ................5 Button/LED Indicate ..............6 Installation ................11 Package Contents ..............11 Specifications ................12 Appendix Table A ..............13 JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... -
Page 3: Feature
Frame rate conversion(1.000/1.001) External Button Configuration Firmware is upgradable in the field using the integrated USB port The converter is Plug-and-Play Support DVI-D, DVI-A, Component, CVBS and S-Video Input JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... -
Page 4: Front Panel
Phone Jack Form you Audio Device plug into this port Component/CVBS/S-Video From your YPbPr/CVBS/S-Video Device plug Input Port into this port From your DVI-D/DIV-A Device plug into this DVI-D/DVI-A Input Port port JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... -
Page 5: Top Panel
Power and Lock LED The LEDs is indicate power and signal locked. Main Format LED The LEDS are indicate output format Side Panel Component Function USB Port Upgrade firmware/Control Box From PC JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... -
Page 6: Button/Led Indicate
Push all button (1, 2 and 3) at same time, the box auto reset to default. 3. Audio Mode Push all button 2 to setting audio Mode.. Embadded Audio (Default) DVI-D External Audio Mute DVI-A Mute YPbPr Composite External Audio SVIdeo JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... - Page 7 Push button 4 change to input source mode. The button 3 and 4 can be switch output source. DVI-D/DVI-A Pb/CVBS Pr/C ● ○ ○ ○ DVI-D ● ○ ○ ○ DVI-A ○ ● ● ● YPbPr ○ ● ○ ○ CVBS ○ ○ ● ● S-VIDEO JMC Systems Engineering AB www.jmc.se +46-8-82 82 70...
- Page 8 1. DVI-D + L/R Audio: DVI-D + L/R Audio 2. DVI-A+ L/R Audio: DVI-A + L/R Audio JMC Systems Engineering AB www.jmc.se +46-8-82 82 70...
- Page 9 3. YPbPr + L/R Audio: YPbPr + L/R Audio 4. Composite (CVBS) + L/R Audio: Composite(CVBS) + L/R Audio 5. S-VIDEO + L/R Audio JMC Systems Engineering AB www.jmc.se +46-8-82 82 70...
- Page 10 Composite(CVBS) + L/R Audio 3. Pattern Genertor Mode: input signal is plug out, the Box auto change to Pattern Genertor mode. It is proivded the 13 of Mode JMC Systems Engineering AB www.jmc.se +46-8-82 82 70...
-
Page 11: Installation
4. Connect the +12DC adaptor to the converter. Package Contents The HD2SDI-S package contains the following items: User Manual x 1 +12 DC Adapter x 1 Combo2SDI Converter x 1 JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... -
Page 12: Specifications
Bottom Output Format/Audio Source/TV Ratio Housing SECC Dimension L:104mm x W:63.3mm xH:26mm Power Source Power Adapter: AC 100 ~ 240 V/DC (+6 ~ 15 V) 0~50°C [32~114°F] Operation Temperature -20~+60°C Storage Temperature JMC Systems Engineering AB www.jmc.se +46-8-82 82 70... - Page 13 1280x720 p60 1280x720 p59.94 1280x720 p50 1920x1080 i60 1920x1080 i59.94 1920x1080 i50 1920x1080 p60 1920x1080 p59.94 1920x1080 p50 1920x1080 p30 1920x1080 p29.97 1920x1080 p25 1920 x 1080 p24 1920 x 1080 p23.98 JMC Systems Engineering AB www.jmc.se +46-8-82 82 70...
