Page 1: User Guide
SDI/HDMI2ANALOG/DVI User Guide Rev1.0 JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70... -
Page 2: Table Of Contents
Front Panel ................4 Rear Panel ................4 Side Panel ................5 DipSwitch/LED Control ..............5 Installation ................13 Specifications ................14 Firmware Upload ..............15 Appendix Table A ..............17 JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70... -
Page 3: Feature
Firmware is upgradable in the field using the integrated USB port The converter is Plug-and-Play Support DVI-D, DVI-A, Component, CVBS and S-Video Output Support stereo audio( L/R Audio ) output JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70... -
Page 4: Front Panel
Phone Jack From you Audio Device plug into this port Component/CVBS/S-Video From your YPbPr/CVBS/S-Video Device plug Output Port into this port DVI-D/DVI-A Input Port From your DVI-D/DIV-A Device plug into this JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70... -
Page 5: Side Panel
Upgrade firmware/Control Box From PC DipSwitch/LED Control Component Function Control Mode Control Box from Dipswitch or USB Input Source Select Input Source Output Source Select Output Source Output Format Select Output Format JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70... - Page 6 Select 1000 or 1001 Frame rate Control Mode: Control Box from Dipswitch or USB. Control Mode Dipswitch Indicates DipSwitch Input Source: Select Input Source from SDI or HDMI Input Source Dipswitch Indicates HDMI JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70...
- Page 7 SDI INPUT HDMI INPUT JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70...
- Page 8 Output Source: Select Output Source(DVI-D/DVI-A/YPbPr/CVBS/SVIDEO) Output Source Dipswitch Indicates DVI-D(HDMI) DVI-A(VGA) YPbPr CVBS+SVideo Output Format: JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70...
- Page 9 720x480p60 1920x1080p50 720x576p50 1920x1080p30 1920x1080p25 720x480i59 1920x1080p24 720x576i50 1920x1080i60 1920x1080i50 1280x720p60 Pss Thru Frame Rate: Select Frame Rate 1000 or 1001 Output Source Dipswitch Indicates 1000 1001 LED Indicate: JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70...
- Page 10 DVI-A(VGA) Output The LED is indicate DVI-A(VGA) Signal YPbPr The LED is indicate YPbPr Signal CVBS/S-Video The LED is indicate CVBS/S-Video Signal Output 1. DVI-D + L/R Audio: DVI-D + L/R Audio JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70...
- Page 11 DVI-D DVI-A YPbPr CVBS/S-Video ● ○ ○ ○ 2. DVI-A + L/R Audio: DVI-A + L/R Audio DVI-D DVI-A YPbPr CVBS/S-Video ○ ● ○ ○ 3. YPbPr + L/R Audio: JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70...
- Page 12 YPbPr + L/R Audio DVI-D DVI-A YPbPr CVBS/S-Video ○ ○ ● ○ 4. Composite (CVBS)+SVideo + L/R Audio: Composite(CVBS) + L/R Audio DVI-D DVI-A YPbPr CVBS/S-Video ○ ○ ○ ● JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70...
-
Page 13: Installation
SDI2MULTI installation consists of the following: 1. Disconnect +12DC adaptor to converter. 2. Connect Video Source to the Input Connector. 3. Connect Display Equipment to the output’s connector 4. Connect the +12DC adaptor to the converter. JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70... -
Page 14: Specifications
Output Format/Audio Source/Input Source Housing SECC Dimension L:153mm x W:63.3mm xH:26mm Power Source Power Adapter: AC 100 ~ 240 V/DC (+9 ~ 15 V) 0~50°C [32~114°F] Operation Temperature Storage Temperature -20~+60°C JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70... -
Page 15: Firmware Upload
Open Upload Firmware Program tools.exe and connect box to PC by USB Cable. Step 2. Plug and un-plug “DC adapter” to power on/off the converter box (the connection check status will be changed to “Connect”) JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70... - Page 16 Step 4. Please click “Start’ Button to proceed with new firmware programming. The PASS message will appear when the procedures finished. Step 5. Close Upload Firmware Program tools JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70...
-
Page 17: Appendix Table A
1280x720 p60 1280x720 p59.94 1280x720 p50 1920x1080 i60 1920x1080 i59.94 1920x1080 i50 1920x1080 p60 1920x1080 p59.94 1920x1080 p50 1920x1080 p30 1920x1080 p29.97 1920x1080 p25 1920 x 1080 p24 1920 x 1080 p23.98 JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70... - Page 18 VESA Mode 1920x1080 p60 1680x1050 p60 1440x1050 p60 1440x900 p60 1400x1080 p60 1366x768 p60 1280x1024 p60 1280x1024 p60 1280x960 p60 1280x800 p60 1024x768 p60 800x600p60 640x480 p60 JMC Systems Engineering AB www.jmc.se info@jmc.se +46-8-82 82 70...
