GAS GRILL
Built-In NG Gas Grill Installation Guide
Assembly - Pg. 7
460 - NG
660 - NG
YOU MUST READ THIS OWNERS GUIDE
BEFORE OPERATING YOUR GAS BARBECUE.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
Leaking gas may cause a fire or explosion
which can cause serious bodily injury or
death, or damage to property.
WARNING:
1. Do not store spare LPG cylinder within
10 feet (3m) of this appliance.
2. Do not store or use petrol or other
flammable liquids or vapors within
25 feet (8m) of this appliance.
#56862
WARNING: Follow all leak-check
procedures carefully in this manual prior
to barbecue operation. Do this even if the
barbecue was dealer-assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this
appliance without reading the Ignition
Instructions section of this manual.
56862 04/28/11 NG
AU - AUSTRALIA

Advertisement

loading
Need help?

Need help?

Do you have a question about the Summit 460 - NG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weber Summit 460 - NG

Summary of Contents for Weber Summit 460 - NG

  • Page 1 GAS GRILL Built-In NG Gas Grill Installation Guide Assembly - Pg. 7 460 - NG 660 - NG #56862 YOU MUST READ THIS OWNERS GUIDE WARNING: Follow all leak-check BEFORE OPERATING YOUR GAS BARBECUE. procedures carefully in this manual prior to barbecue operation.
  • Page 2 WARNING: All countertop finished surfaces must be constructed of a noncombustible material. TOLERANCES 34" (864 mm) 42" (1067 mm) ±1/4" (6 mm) 36" (914 mm) 36" (914 mm) 24 5/16" (618 mm) 24 5/16" (618 mm) ±1/4" (6 mm) WWW.WEBER.COM ®...
  • Page 3 BUILT-IN CUTOUT DIMENSIONS GENERAL CONSTRUCTION DETAILS The Summit ® Built-In unit should be on site before construction begins. For ease of installation, the grill will be pushed on its casters into the built-in structure. The installation of this grill requires a level floor pad surface (1) and countertop surface. The floor pad surface must be constructed from solid materials and must be level and smooth.

  • Page 4: Gas Supply

    GAS SUPPLY BUILT-IN GAS LINE LOCATIONS BUILT-IN GAS LINE LOCATIONS Note: Leave an access in the “island” structure for gas supply and regulator service that is not inside the grill structure. Note: Area should be kept clear of sharp, jagged, or extremely abrasive surfaces to avoid possible damage to gas supply lines.

  • Page 5: Gas Supply Connection

    A) Hard pipe the gas supply to an access for gas supply shutoff. B) Connect the gas supply line (from the gas supply shutoff) to the regulator. Front view of typical natural gas routing From gas supply Regulator Gas Flow Right side panel of grill WWW.WEBER.COM ®...
  • Page 6 ATTENTION: This product has been safety tested and is only certified for use in a specific country. Refer to country designation located on outer carton. These parts may be gas carrying or gas burning components. Please contact Weber-Stephen Products LLC Customer Service Department for genuine Weber-Stephen Products LLC replacement part(s) information.
