Cooktop Installation - Haier HCC2430AGS Installation Instructions Manual

x
Excessive Weight Hazard
Use two or more people to move and install cook-
top.
Failure to do so can result in back or other injury.
x
Cut Hazard
Beware of sharp edges. Use the polystyrene ends
when carrying the product. Failure to use caution
could result in minor injury or cuts.
x
Always consult the countertop manufacturer for
specific instructions.
x
Ensure the countertop is square and level and en-
sure no structural members interfere with space
requirements.
x
Prepare the cut-out according to the instructions
(see cut-out dimensions).
x
Make sure the wall coverings, countertop and
cabinets around the cooktop can withstand heat
(up to 200 °F).
Figure 5. Tools you will need
Step 1
Remove packaging materials and literature package
from the cooktop before beginning installation.
Remove Installation Instructions from literature pack
and read them carefully before you begin.
8

Cooktop Installation

WARNING
Cooktop Installation Manual
Figure 6. Parts
006
ENGLISH
MANUAL
GASKET
GAS CONVERSION KIT
GAS CONNECTION KIT
SIMMER PLATE (if present)
WOK RING (if present)
POT ADAPTER (if present)
PRESSURE
REGULATOR
COOKTOP
GRID
CARDBOARD
