- Page 1 Easy Run1.1T TREADMILL USER MANUAL...
- Page 2 Dear Customer, We are pleased, that you have chosen a Casall Fitness Equipment. This quality product has been designed for in-home use and has been tested and certified according to the European Norm EN 957-1/6. Please carefully read the instructions prior to assembly and first use and be sure to keep the instructions for reference and maintenance.
- Page 3 Please have the product model name, number and serial number ready when you call. Advice The owner’s manual is only for the customer reference. Casall Fitness can not guarantee for mistakes occurring due to translation or change in technical specification of the product.
- Page 4 Precautions Before assembling or using the treadmill, please read the following instructions carefully. They contain important information for use and maintenance of the equipment as well as for your personal safety. Keep these instructions in a safe place for maintenance purposes or for ordering spare parts. Product-Scope: This product is made for home use only and tested up to a maximum body ...
- Page 5 Product-Preparation: Follow the steps of the assembly instruction carefully. Product-Preparation: Only use suitable tools for assembly and ask for assistance if necessary. Product-Preparation: Only use original Casall Fitness parts as delivered (see checklist). Product-Preparation: Tighten all adjustable parts to prevent sudden movement while training. ...
- Page 6 WARNING! Heart rate monitoring systems may be inaccurate. Over exercising may result in serious injury or death. If you feel faint stop exercising immediately. Product-Maintenance: Incorrect repairs and structural modifications (e.g. removal or replacement of original parts) may endanger the safety of the user. Routine cleaning of your treadmill will extend the product’s life.
- Page 7 Check list...
- Page 8 ASSEMBLY INSTRUCTIONS...
- Page 11 Safety key operating instructions...
-
Page 12: Folding Instructions
FOLDING INSTRUCTIONS... - Page 14 FOLDING INSTRUCTIONS...
- Page 15 FOLDING INSTRUCTIONS...
-
Page 16: Unfolding Instructions
UNFOLDING INSTRUCTIONS... - Page 17 UNFOLDING INSTRUCTIONS...
- Page 19 Manual adjust incline level...
- Page 20 Transportation...
- Page 21 Correct use...
- Page 22 Deck Lubrication The walking belt has been pre-lubricated at the factory. However, it is recommended that the running board be checked periodically for lubrication to ensure optimal treadmill performance. Your treadmill should not have to be lubricated usually within the first year or 500 hours of use. Every 30 days or 30 hours of operation lift the sides of the walking belt and feel the top surface of the walking board as far as you can reach.
-
Page 23: Belt Adjustment
Belt adjustment Belt adjustment and tension performs two functions: adjustment for tension and centering. The running belt has been adjusted properly at the factory. However transportation, uneven flooring or other unpredicted reasons could cause the belt to shift off center resulting in the belt rubbing with the plastic side rail or end caps and possibly causing damage. - Page 24 A MAJORITY OF THE PARTS SHOWN HERE HAVE BEEN PREASSEMBLED AT THE FACTORY.
- Page 29 605 842 854 852 713 714...
-
Page 30: Wiring Diagram
WIRING DIAGRAM... - Page 31 Spare Part List Part No. Part name Console housing holder Console housing decorate cover-upper Console housing lower Computer console housing -rear safety key safety key box Overlay Covering Keys Upright-left Upright-Right console support frame pulse sensor uptight lower cover Fold locker cover-right Fold locker cover-right fold locker Left handlebar cover -outer...
- Page 32 Front transport frame lower cushion Transportion wheel front foot Connect tube M8X18.5 ball head M8X42.5 ball head Cliper ∮1X42 Transportion Wheel side cover motor cover top motor holder 8X26X11 PU cushion DC motor driving belt Front motor cover –left Front motor cover –right motor cover -lower Running belt Side rail –left...
- Page 33 transformer Main frame front roller Cross bar eva sheet Rear roller Main frame cross bar power plate cover Cushion 10X20X22 power plate Cliper OD12X12X31 Cliper OD7X10X24 Round cushion Rear transport braket Transport wheel Transport braket end cap Deck cushion 4X12 mm screw M3X8 mm screw M4X15 mm screw 3X14 mm screw...
- Page 34 Clip ring M25 Φ8X23X2 mm washer Spring ∮3x27 M8X20X76.5X∮12.5 bolt 5.3X50 mm lock pin 4.2X16 mm screw Spring metal 21X13X0.7 M4X12mm screw M8X14X4mm nut Φ10X15.5 mm washer M8 thin nut M8 nut Φ8X17X1.5 washer Φ16X26X2 mm washer Φ10X33X2 washer 14X19.5-18X15.5-22X4 bushing 10X22.7-18X18.7-22X4 Bushing ID12X46.5-16X43.5-20X3 bushing M10x40x10 Bolt...
- Page 35 M5X14 mm screw M4X19 mm screw M8X30mm bolt M6X65 bolt Ф6X13X1.5 washer M8X33.8 bolt API12-850 M6X8X29.5XФ12.5 bolt API12-851 Ф6.2X40X1 flang washer M10X52X14 mm screw Ф10X26X2 mm washer Metal bushing 10x7.6 M3X8mm screw M6X8-10X66 Pressure springФ1.2X13.6X60X11 Foot cushion stationary axis 7.8X55.8-M4X10-M6X10 Clip ring M15 M4X6 Screw...
-
Page 36: Mode Button
Computer instruction Before assembling or using your fitness equipment, please carefully read the precautions included in the assembly instructions. MODE BUTTON STOP/ENTER BUTTON SLOW BUTTON FAST BUTTON START BUTTON LCDD ISPLAY START Press to start exercise initial speed 0.5 ml/0.8 km. STOP / ENTER 1. -
Page 37: Computer Operation
FAST/SLOW BUTTON 1. Press to increase/decrease exercise speed by 0.1ml /km. 2. Hold the button to increase/decrease rapid speed by 0.1ml/km per second and release the button to stop the function. Press to select programs and preset related function value. MODE BUTTON Please MODE button the exchange the display IMPORTANT... - Page 38 -CALORIES: Accumulates and displays calories consume during workout time. -SPEED: Displays current speed. PROGRAM1–TIME 1. Press STOP/ENTER to confirm the program and press START button to start exercise. 2. Press STOP/ENTER before starting exercise to run presetting procedure, with P1 blinking. 3.
- Page 39 PROGRAM4–15 MINUTES PRESET SPEED 1. Press STOP/ENTER to confirm the program. 2. Press START key to start the exercise, or press STOP/ENTER before starting exercise to run preset procedure with P4 blinking. 3. The LCD will display “L1” after press the STOP/ENTER button, and press SPEED UP/DOWN to select the level from L1 to L7, and then press STOP/ENTER button to confirm.
- Page 40 LEVEL TIME 30~29 29~27 27~23 23~19 19~12 12~5 KM/ML 0.8/0.5 1.6/1.0 4.8/3.0 6.4/4.0 7.2/4.5 4.8/3.0 3.2/1.0 1.6/1.0 KM/ML 0.8/0.5 3.2/2.0 5.6/3.5 7.2/4.5 8.0/5.0 5.6/3.5 4.0/1.5 1.6/1.0 KM/ML 0.8/0.5 4.0/2.5 6.4/4.0 8.0/5.0 8.8/5.5 6.4/4.0 4.8/3.0 1.6/1.0 KM/ML 0.8/0.5 4.8/3.0 7.2/4.5 8.8/5.5 9.6/6.0 7.2/4.5 5.6/3.5...
- Page 41 LEVEL TIME 9~7 7~3 3~2 2~1 1~0 1.6/ 2.4/ 4.8/ 7.2/ 4.8/ 6.4/ 7.2/ 4.8/ 6.4/ 7.2/ 4.8/ 6.4/ 7.2/ 4.8/ 6.4/ 7.2/ 4.8/ 6.4/ 7.2/ 3.2/ 1.6/ 3.2/ 5.6/ 8.0/ 5.6/ 7.2/ 8.0/ 5.6/ 7.2/ 8.0/ 5.6/ 7.2/ 8.0/ 5.6/ 7.2/ 8.0/...
