OC Panel II specifications summary

Display
Features
I/O Ports
Installation
Requirements
Compatibility
xvi
2.6" LCM display
EXTREME/NORMAL mode switch
EXTREME Mode for subzero OC benching:*
- VGA Hotwire
- Subzero Sense
- Slow Mode
- Pause Switch
- VGA SMB header
- ProbeIt
- 4 x 4-pin extra fan connectors [2 x PWM fan connector]
- 2 x Thermal sensor connectors
NORMAL Mode for in-chassis usage:**
- O.C. button
- FanSpeed control button
- LCM backlight on/off button
* Extreme Mode capabilities, including V1, V2, DRAM and other voltage
definitions, vary by chipset. Please refer to your motherboard manual
for details.
** One 5.25" drive bay is required for NORMAL Mode installation.
POWER : 1 x SATA power connector
ROG_EXT port : 1 x 18-1 pin data connection port
1 x 5.25-inch drive bay required for NORMAL Mode installation
1 x SATA power cable from system power supply
MAXIMUS VIII EXTREME and other motherboards with ROG_EXT
port
* Visit the ASUS website at www.asus.com for the latest motherboard
support/compatibility lists.
** Install the latest utility/firmware (ROG Connect Plus) for better
compatibility.
