LED
(ACT)
(LINE)
(Phone1/Phone2)
(Wireless LAN
On/Off/WPS)
DSL (Green)
~
LAN1/2/3/4
~
USB1/2
Vigor2760 Series Quick Start Guide
o
r
2
7
6
0
V
n
o
r
2
7
6
0
V
n
Status
Blinking
Off
On
Off
On
Off
Blinking
On (Green) The wireless access point is ready.
Blinking
(Green)
Blinking
(Orange)
Off
On
Blinking
(Slowly)
Blinking
(Quickly)
On
Blinking
On
Explanation
The router is powered on and running
normally.
The router is powered off.
A PSTN phone call comes (in and out).
However, when the phone call is
disconnected, the LED will be off for
awhile.
There is no PSTN phone call.
The phone connected to this port is
off-hook.
The phone connected to this port is
on-hook.
A phone call comes.
The data is transmitting via wireless
connection.
Blinks with one second cycle for two
minutes. The WPS function is active.
The wireless access point is turned off.
The DSL port is connected.
The router is ready.
The router is trying to connect to
Internet.
The port is connected.
The data is transmitting.
A USB device is connected and active.
