- Page 1 CLASS 1 LASER PRODUCT LOUKAN 1 LASERLAITE KLASS 1 LASERAPPARAT Model CDR510 User Guide CD Recorder/CD Player ® Recordable...
-
Page 2: Laser Safety
Warnings and Cautions CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. This unit employs lasers. -
Page 3: Note To Catv System Installer
CE marking (only EU version) Equipment mains working system This product complies with household power and safety requirements in your area. CDR510 can be powered by 120 V AC only. This Class B digital apparatus complies with Canadian ICES-003. - Page 4 VARNING! OSYNLIGH LASERSTÄLNING NÄR DENNA DEL ÄR ÖPPNAD OCH SPÄRREN ÄR URKOPPLAD. BETRAKTA EJ STRALEN. charges. • Do not place heavy objects on the unit. • Be sure the CDR510 is placed on a vibration-free surface. Precautions - connection • Unplug the power cord from the AC outlet or turn off the POWER switch before making any connection.
-
Page 5: Important Safety Instructions
Important Safety Instructions This product was designed and manufactured to meet strict quality and safety standards. There are, however, some installation and operation precautions which you should be particularly aware of. Read Instructions – All the safety and operating instructions should be read before the product is operated. -
Page 6: Table Of Contents
11 Track Skip backward button 12 Fast backward search button 13 SCROLL button ... 26 14 PAUSE button 15 Stop button *Controls in italics do not function on the CDR510. (table of contents continues) - 6 - page ... 21 ... - Page 7 Troubleshooting ... 54 Specifications ... 55 LIMITED WARRANTY ... 56 Introduction The CDR510 CD Recorder/CD Player is a professional page CD Recorder and a professional CD Player in the same unit. The CD Recorder and CD Player can be operated as independent devices. That saves you ...
-
Page 8: Features
• CD drive only, finalized MP3 data discs Play back track selection • Single track: one track plays and the CDR510 stops at the beginning of the next track • Scan Play: plays the first 10 seconds of each track •... -
Page 9: Connections (Basic)
Package contents CD RECORDER / CD PLAYER CDR510 PLAY MODE REC LEVEL / SELECT POWER MENU/ ERASE TIME MODE STORE TEXT FINAL CANCL/ INPUT DELETE PUSH ENTER ALBUM CDR510 unit Infrared remote control Power cord Audio cables (2) 3' 3" (100 cm) -
Page 10: How To Play Back
CHANGER mode CHANGER mode is the default play mode of the CDR510. The CD drive and CDR drive work as one for playing two CDs, selecting tracks, and programming track play back sequence. A program can switch between drives. Only one of the drives can play back at a time. -
Page 11: Play Back Features
CHANGER mode only. In scan the first 10 seconds of each track is played. The CDR510 automatically stops after all tracks on both discs are scanned. From stop, push and release the SCAN button on the IR remote. Push and release the SCAN button or the Play/Pause button drive to exit scan and continue play back. -
Page 12: To Record From The Cd Drive
• Use discs compatible with a 1X write speed. See page 49. • If the disc already contains recordings, the CDR510 will automatically locate the end of the last recorded track and start from there. • Tracks from the CD drive can be programmed for recording. -
Page 13: To Record From An External Source
REC EXT MAN – recording from an external source by manually starting recording. MINUTE TRACK – automatically start a new track every minute. See page 40 for more details about Recording modes. CD RECORDER / CD PLAYER CDR510 PLAY MODE REC LEVEL / SELECT POWER MENU/ ERASE... -
Page 14: Notes Regarding Recording
See TEXT EDIT page 29. Copy protection • Because this is a professional CD recorder copy protected CDs can be copied. • The CDR510 allows you to set the copy protection of recorded discs. See page 35. Additional Recording Information •... -
Page 15: Cdr Drive (Disc Tray)
(a) indicating CD drive is selected. ANALOG Pitch adjustments remain even when discs are changed or the CDR510 is powered off. - 15 - CD - R ANALOG 6. CD button Press and release to select the CD drive. -
Page 16: Play/Pause Button
During recording, press and release to pause recording. When recording is paused, press and release to resume recording. The CDR510 must detect a CD-RW disc with at button (a) to least one track on it in the CDR drive. "ERASE TRACK"... -
Page 17: Rec Level/Select Control
The CDR drive is selected. b. The CDR510 is in CHANGER mode. c. Track 2 is flashing indicating it is selected. d. Track 2 is displayed indicating it is selected. -
Page 18: Final Button
CD RECORDER / CD PLAYER CDR510 PLAY MODE REC LEVEL / SELECT POWER ERASE MENU/ MODE STORE TIME TEXT CANCL/ FINAL INPUT DELETE PUSH ENTER ALBUM 19 20 21 REC LEVEL / SELECT MENU/ ERASE TIME TEXT PROG MODE STORE... -
Page 19: Cancl/Delete Button
When ANALOG is selected the input for recording is from either the ANALOG L and R IN RCA jacks or the BALANCED IN XLR jacks on the rear of the CDR510, depending on the setting of the INPUT SELECT switch on the rear of the CDR510. -
Page 20: Alphanumeric Display
Display CD RECORDER / CD PLAYER CDR510 PLAY MODE REC LEVEL / SELECT POWER ERASE MENU/ TIME MODE STORE TEXT FINAL CANCL/ INPUT DELETE PUSH ENTER ALBUM 2 3 4 5 7 8 9 TIME TRACK TOTAL TRACK TIME SYNC... -
Page 21: Recording Icon
CD RECORDER / CD PLAYER CDR510 PLAY MODE REC LEVEL / SELECT POWER MENU/ ERASE TIME TEXT MODE STORE FINAL INPUT CANCL/ DELETE PUSH ENTER ALBUM TIME TRACK TOTAL TRACK TIME SYNC DUBBING CHANGER MANUAL CD - RW ANALOG 28 29 CD - RW 17. -
Page 22: Balanced In Analog Xlr Inputs L & R
CD RECORDER / CD PLAYER CDR510 PLAY MODE REC LEVEL / SELECT POWER MENU/ ERASE TIME TEXT MODE STORE FINAL INPUT CANCL/ DELETE PUSH ENTER ALBUM TIME TRACK TOTAL TRACK TIME SYNC DUBBING CHANGER MANUAL CD - RW ANALOG 30 31 30. -
Page 23: Input Select Switch
See TRIM (4). The INPUT SELECT SWITCH (6) on the rear of the CDR510 must be to the left to select the BALANCED IN inputs. ANALOG must also be selected by pressing and releasing the INPUT button on the front of the CDR510 so ANALOG is displayed. -
Page 24: Digital In & Out Connectors (Spdif)
Connect a digital audio cable with RCA jacks from an external device providing SPDIF digital output. To record from this input DIGITAL must be selected by pressing and releasing the INPUT button on the front of the CDR510 so DIGI is displayed. Example display... -
Page 25: Door Open/Close Button
CDR510 to be controlled remotely. The REMOTE EXT / INT (IR) switch (a) on the back of the CDR510 must be at INT (left position) for the infrared remote to work. See Remote batteries on page 9 for installing or changing the remote batteries. -
Page 26: Display Button
CDR510. See page 15. 10. MENU button MENU Works the same as the MENU/STORE button on the CDR510. See page 16. 11. Track Skip backward button Press and release during Play or Play pause to skip backward to the begin- ning of the current track. -
Page 27: Rec Button
25. REC TYPE button Not used. 26. SOURCE button SOURCE Works the same as the INPUT button on the CDR510. See page 27. ENTER button ENTER Works the same as pushing and releasing the REC LEVEL / SELECT control on the CDR510. See page 21. -
Page 28: Menu Mode
The chart also lists the default setting applied by the factory, and if the setting is remembered if the CDR510 is powered off and back on again. 'See Page' lists the page number for detailed instructions on the menu item. -
Page 29: Text Edit
To make a menu change: 1. Push and release MENU/STORE button to enter Menu mode. 2. Turn the REC LEVEL/SELECT control to advance through the menu choices. 3. When the menu choice you want to change is displayed, push and release the REC LEVEL/SELECT control to enter that choice. -
Page 30: Text Erase
TEXT ERASE (How to erase CD Text) 1. With the CDR drive selected and an unfinal- ized CD that includes CD Text detected in the CDR drive, push and release the MENU/ STORE button. 2. Turn the REC LEVEL/SELECT control so TEXT ERASE is displayed. -
Page 31: Auto Track
When AUTO TRACK is ON and the digital source does not include track ids, the CDR510 will use a silence gap to mark a track. A track can also be incremented by pressing and releasing the TR. -
Page 32: Auto Stop
AUTO TRACK must be ON for AUTO STOP OFF or ON to function. AUTO STOP OFF When recording with AUTO STOP OFF the CDR510 will record until stopped by pressing the Stop button. The benefit of AUTO STOP OFF is, for example, when recording classical music, which could have long passages of silence. -
Page 33: Rec Balance
Balance adjustment Balance adjustment is only available in record or record standby mode, for example when REC EXT DISC is selected and the CDR510 is waiting for the external source to start. Balance is adjustable by independently adjusting the record level of the Left and Right channels. -
Page 34: Src
The CDR510 can perform SRC (Sample Rate Conversion) on an incoming digital signal for recording. The CDR510 is capable of handling digital sources from 11 kHz up to 56 kHz. The CDR510 monitors the incoming digital signal to check if the signal is 44.1 kHz (±100 ppm). -
Page 35: Copy Protection
Because the CDR510 is a professional CD recorder, it will record from any digital source, ignoring the copy protection setting of the source material. The CDR510 allows you to set the level of copy protection of each disc you record. COPY OFF A CD recorded with COPY OFF allows unlimited digital copying. -
Page 36: Pitch
When pitch is active the green PITCH indicator on the front of the CDR510 is lit and steady. Pitch settings remain when discs are changed or if the CDR510 is powered off. -
Page 37: Auto Cue
AUTO CUE (CD drive and Dual mode only) AUTO CUE allows the CD player to advance to the beginning of the audio within the track, rather than start play back from the track start flag. This minimizes the silence at the beginning of play back. -
Page 38: Play Mode
AUTO CUE is on it is cued according to the setting of AUTO CUE. When at NEXT CUE, when a track is completed the CDR510 is paused to begin the next track. If AUTO CUE is on it is cued according to the setting of AUTO CUE. -
Page 39: End Warning
END WARNING (CD drive and Dual mode only) When END WARNING is on the remaining time display flashes as the end of a track is ap- proached during play back. END WARNING can be set from 0 to 35 seconds in 5 second increments. -
Page 40: Recording Modes
Choosing the Recording mode is usually the last step before actual recording (pressing the REC button to begin recording). The CDR510 is set to expect you have the disc you want to record on in the CDR drive, chosen the audio source, made necessary connections, and made necessary menu adjustments. -
Page 41: Rec Mp3 Disc, Make Cd
CDR510 or the DISPLAY button on the remote to display the remaining disc time. Minute Track marks are silent. Playback across a Minute Track does not produce any sound. CD Text can be added after the copy is made and before finalizing. -
Page 42: Mp3
Audio Layer 3.” Files with the “.mp3” or “.MP3” extension are called MP3 files. The ID3 tag is supported by the CDR510. ID3 is a format that adds title information to MP3 files. **The following technical issues can result in MP3 incompatibility with the CDR510: •... -
Page 43: Mp3 Load
MP3 LOAD MP3 LOAD lets you load MP3 instructions without inserting an MP3 disc. How to MP3 LOAD 1. With AUTO MP3 LOAD off, with the CD drive selected, and with no disc* in the drive, push and release the MENU/STORE button. *If AUTO MP3 LOAD is on, MP3 instructions were loaded on power up. -
Page 44: Mp3 Album/File Structure
MP3 Album/file structure Example play sequence as displayed in Windows Explorer: Album 02 Album 03 aaaa03.mp3 aaaa04.mp3 aaaa05.mp3 aaaa06.mp3 Album 04 Album 05 bbbb07.mp3 bbbb08.mp3 Album 06 Album 07 dddd11.mp3 dddd12.mp3 eeee13.mp3 eeee14.mp3 Album 08 Album 09 wwww.wav xxxx.wav ffff15.mp3 AAAA01.mp3 Root BBBB02.mp3 Album 01 Play up to 8 hierarchical levels possible. -
Page 45: How To Program Tracks
How to PROGRAM tracks Track sequence can be programmed for playback or recording. From stop in CHANGER or DUAL MODE, push and release the PROG button to enter Program mode. Example display CD - R ANALOG "PROGRAM" (a) will be displayed briefly, then PROGRAM (b) will be flashing. -
Page 46: Finalizing
• A finalized CD-R disc can never be recorded onto again • A finalized CD-RW disc can be unfinalized for more recording • The CDR510 can play back unfinalized CD-R or CD-RW discs in both drives • The MAKE CD recording mode automatically finalizes the recorded disc... -
Page 47: Unfinalizing
If the CD-RW disc has been finalized it must first be unfinalized before it can be erased. With the CD-RW disc in the CDR drive and at stop: 1. Push and release the ERASE button. CD RECORDER / CD PLAYER CDR510 PLAY MODE REC LEVEL / SELECT POWER MENU/... -
Page 48: Display Messages
DISPLAY messages Display messages listed below may appear for your guidance. ALBUM TITLE ... followed by album title ALL TEXT ... entering all text display mode ANALOG ... analog input selected AUTO TRACK ... selecting AUTO TRACK on or CHANGER MODE . control attempted during dual mode that only applies to changer mode CLOSE ... -
Page 49: About Compact Discs
• Some CD players can not play finalized CD-R discs because of the low reflectivity of such discs. Which discs to use: The CDR510 is able to record onto any 1X compatible CD-R and CD-RW disc, including discs for Consumer use and Professional (com- puter) discs. - Page 50 • Do not use record cleaner, it will adversely affect the disc surface. • Store discs in their disc cases. • Do not attach a piece of paper or sticker to the label side of the disc. When a disc has a piece of plastic tape or rental CD label with paste protruding from the edge or when a disc has a trace of such as sticky object, do not attempt to play the disc.
-
Page 51: Rs-232C Control
• The RS-232C host can control functions of the CDR510 externally • The CDR510 automatically transmits status data when status is changed. • The CDR510 will respond to status requests by transmitting the associated status data. Control commands: Command CD command "@12000"+CR... - Page 52 Total Lap Track "@1?26TRAC"+CR Current Display "@1?26TIME"+CR Time Hand shake flow chart for Commands Requesting Status: CDR510 Status Request Command Status Command Status changes automatically transmitted. The following status codes are automatically transmit- ted to the host. Status from CD Category...
-
Page 53: Codes
CDR510 from Marantz Professional) can control the CDR510 CTS out using these RC-5 codes. The CDR510 receives the codes listed in the table below from the infrared remote control sensor on the front of the unit and also the REMOTE RC-5 IN/OUT jacks. -
Page 54: Troubleshooting
TROUBLESHOOTING Should faults occur, it is in many cases not necessary to consult your dealer or technical service department. On the basis of the following checks, you will be able to rectify a number of conditions yourself without difficulty. If the condition cannot be remedied after the following check, please consult your dealer or contact D &... -
Page 55: Specifications
Coaxial Digital In/Out (RCA) ... 0.5 Vp-p /75 Optical Digital Input ... -19 dBm Digital Input Sampling Frequency ... 32/44.1/48 kHz (11 ~ 56 kHz) CD Player Applicable Discs ... CD, CD-R, CD-RW, MP3 disc Frequency Response ... 20Hz ~ 20kHz +0/-0.5 dB Signal to Noise Ratio (IEC-A) ... -
Page 56: Limited Warranty
Manufacturer shall not be liable for damage to other products caused by any defects in Marantz products, damages based on inconvenience or loss of use of the product, or any other damages, whether incidental, conse- quential, or otherwise. - Page 57 ® Marantz is a registered trademark. 2003/8...
