Manitowoc K00099 Installation Instructions

K00099/K00150 WATER FILTER BIN BRACKET
Installation Instructions
1. Water filter bin bracket can be used to mount all Tri-liminator water filter assemblies on either side or back of any
Manitowoc ice bin.
2. Remove foam tape from area where bracket is to be mounted, hang bracket, and install foam tape, provided with kit,
over top of bracket. Locate ice machine, per installation instructions.
3. Using screws and flatwashers provided, fasten Tri-liminator assembly to bracket.
Ice Bin
Manitowoc Ice, Inc.
2110 South 26 Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA
Telephone 920-682-0161, Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879
8008693
Web Site - www.manitowocice.com
Rev. 05/24/99

Water Filter Bin Bracket

#10-24 x 1/2 Lg. Screw

Foam Tape

and Flatwasher
Tri-liminator
Assembly
