Serial Port Configuration; Apm Configuration - Asus B150 PRO GAMING D3 User Manual

Asmedia USB 3.1 Controller [Enabled]
[Enabled]
[Disabled]
Asmedia USB 3.1 Battery Charging Support [Disabled]
This item appears only when the Asmedia USB 3.0 Controller item is set to [Enabled].
[Enabled]
[Disabled]
Intel LAN Controller [Enabled]
[Enabled]
[Disabled]
Intel PXE Option ROM [Off]
This item appears only when you set the previous item to [On] and allows you to enable or
disable the PXE OptionRom of the Intel LAN controller. Configuration options: [On] [Off]
USB Type C Power Switch [Auto]
[Auto]
[Enabled]

Serial Port Configuration

The sub‑items in this menu allow you to set the serial port configuration.
Serial Port [On]
Allows you to enable or disable the serial port (COM).Configuration options: [On] [Off]
Change Settings [IO=3F8h; IRQ=4]
This item appears only when you set the Serial Port to [On] and allows you to select
the Serial Port base address. Configuration options: [IO=3F8h; IRQ=4] [IO=2F8h;
IRQ=3] [IO=3E8h; IRQ=4] [IO=2E8h; IRQ=3]
2.6.8

APM Configuration

ErP Ready [Disabled]
Allows BIOS to switch off some power at S4/S5 to get the system ready for ErP requirement.
When set to [Enabled], all other PME options will be switched off. Configuration options:
[Enable(S4+S5)] [Enable(S5)] [Disabled]
Restore AC Power Loss [Power Off]
[Power On]
[Power Off]
[Last State]
2‑30
Enables the onboard USB 3.0 controller.
Disables the controller.
Enables the Asmedia USB 3.0 battery charging function.
Disables this function.
Enables the Intel LAN controller.
Disables the controller.
Turns off power to the Type C port when the device is not supported.
Turns on power to the Type C port.
The system goes into on state after an AC power loss.
The system goes into off state after an AC power loss.
The system goes into either off or on state, whatever the system state was
before the AC power loss.
Chapter 2: Getting started
