2. Front Panel

M2TECH
OUTPUTS
POWER ON
EVO SUPPLY TWO
LOW N OISE POWER SUPPLY
1 2 3
Figure 1
1) Power on LED. It glows when the EVO SUPPLY TWO is operational, that is when the
mains switch on the back panel is in the "1" position.
2) Outputs toggle button. Use this button to enable/disable the outputs..
3) Outputs activation LED. It glows when the outputs are enabled.
