M2TECH

VAN DER GRAAF M

VERY LOW NOISE POWER SUPPLY

USER MANUAL

REV. P

B – 8/2017

Table of Contents

Need help?

Do you have a question about the VAN DER GRAAF MKII and is the answer not in the manual?

Questions and answers

Summary of Contents for M2TECH VAN DER GRAAF MKII

Page 1 M2TECH VAN DER GRAAF M VERY LOW NOISE POWER SUPPLY USER MANUAL REV. P B – 8/2017...
Page 3 WARNING: the information contained in this manual are considered to be reliable and accurate. M2Tech reserves the right to change or modify the information any time, without prior advice. It’s up to the customer to ensure that the manual being consulted is the latest version.
Page 4 We’re sure that your expectations will be fulfilled by purchasing VAN DER GRAAF M II: your M2Tech products will exhibit an incredible increase of their sonic performance, so you can now prepare for a whole new listening experience! Nadia Marino, CEO...
Page 5: Table Of Contents
5. Cleaning the Unit ......................13 6. Outputs Toggle ......................15 6.1. Setting and changing the activation sequence ............15 7. Setting the VAN DER GRAAF M II to sense IR on/off commands ........17 8. Overload and Protection ....................17 9. Specifications.........................19 Copyright © 2017, M2Tech Srl...
Page 7: Unpacking And Placing The Unit
Avoid smoke, moisture, dirt and liquids from reaching the unit. Please note that any signs of abuse will void warranty coverage. Do not place the unit on thick carpets or inside a box or piece of furniture, not even close to curtains. Copyright © 2017, M2Tech Srl...
Page 9: Front Panel
6) IR receiver. The VAN DER GRAAF M II senses the on/off commands from other M2Tech products’ remote controls, when purposely set by the user. Operation is same as the global enable button (item 2, Fig. 1).
Page 11: Back Panel
+5V/+15V/-15V (e.g. the NASH) to this outputs using the stock cables. Female 4-pole XLR sockets. 8) Single voltage outputs. Connect M2Tech units provided with input for single 15V or 9V supply and maximum current sink 500mA (e.g. the Young MkIII) to this outputs, using the stock cables.
Page 13: Connecting And Powering The Unit
Avoid fluids from dropping or leaking inside the unit. Fluids of any type poured into the unit will void your warranty. Be careful not to scratch the Plexiglas front screen. Copyright © 2017, M2Tech Srl...
Page 15: Outputs Toggle
When VAN DER GRAAF M II is active, it can be put in standby pushing the global enable button once more or, when purposely set, by another on/off command from an M2Tech Rockstars product’s remote control. Following this action, the global enable LED starts blinking and the active outputs are shut down in the reverse order with respect to the activation order.
Page 17: Setting The Van Der Graaf M
7. Setting the VAN DER GRAAF M II to sense IR on/off commands When used in an all-M2Tech system, the Van Der Graaf M II can power all the other units in the right order by a single remote control’s button push. This can be easily...
Page 19: Specifications
Output reset: ........inverse sequence with regards to activation Size:..........200x50x200mm (w x h x d) Weight..........2.4kg (device and ancillaries) 2.9kg (packed) * maximum total current available on each of the two outputs rails is 1,5A Copyright © 2017, M2Tech Srl...
