Compact CP 30SC E Service Manual page 5

F.A.G. SRL
ME-CPT1-199
↑
T
S
↓
B
→
↑
F
←
C
Compressor
V Fan motor
VG Hot gas valve
VC Condenser water valve
TSA Safety thermostat
T Capillary tube
CA Water cooled condenser
REFRIGERATION TUBING SCHEMATICS
E
←
C
→
TE
WATER COOLED
SELF CONTAINED UNITS WITH TIMER
COMPACT SERVICE MANUAL
VG
→
V
←
TSA
PT
Pressure switch
TE Evaporator thermostat
F Molecular sieve
E Evaporator
B Receiver
S Heat exchanger
⇐
Water inlet
⇒
Water drain
PAG.3
⇒ ⇒ ⇒ ⇒
2
CA
VC
⇐ ⇐ ⇐ ⇐
1
PT
230V
