1. Choose a location far from heating sources and in a well ventilated dry place, not dusty, near
water inlet & drain connections.
2. Provide enough clearance at both sides and at rear of the unit (20 cm at least).
DO NOT USE UNIT OUTSIDE AND DO NOT EXPOSE IT TO RAIN.
3. Set upstream of the units an electrical multi-pole disconnect switch having a contact separation
of at least 3 mm in all poles. Switch rating shall comply with power specifications of each ice-
maker, as per specifications given in the plate on rear of each unit.
ALL CONNECTIONS SHOULD BE MADE IN ACCORDANCE WITH EXISTING
4. Power supply must match voltage specifications on registration plate on rear of unit. +/- 6%
deviation permitted. On higher rushes no assurance of correct operation is given.
5. Water inlet should be regulated by a 3/4" threaded tap, for an easy installation of the supply hose.
ATTENTION! CONNECT UNIT TO DRINKING (POTABLE) WATER ONLY.
6. Check if water inlet pressure is between 1 to 3 bar. If it is higher, install a pressure reducer set at
2,5 bar.
7. Water outlet must be at ground level connected to an open vented siphon.
2.B.a. AIR COOLED CONDENSER UNITS
1. Unpack the ice maker without turning the unit upside down, check for damage, remove all
cartons and the wooden pallet.
2. Remove the bag with the accessories from inside the unit. Take care of the Final User Manual
and give it to your customer. Remove the water blinds assembly. Check that the water spray-bar
and the internal ice chute are in the correct position, then re-install water blinds assembly.
3. Connect the unit to the external multi-pole switch for electric supply.
4. Check that the unit is perfectly level. If required, adjust leveling feet.
5. Connect the water inlet solenoid valve to the water mains tap with the rubber water supply tube.
6. Connect a drain hose to the water outlet of the unit and the open vented siphon at floor level.
7. Clean walls and bottom of storage bin with a wet cloth.
8. Open tap on water mains and check for leakage.
9. Switch on main external disconnect switch.
10. The unit starts in defrost at first installation. Water is charged and fills water tank. When the
timer ends the defrost cycle, the freezing cycle begins.
11. After a shut-off period, it is possible that the unit will not re-start in defrost. In this case or in
case more water is needed, turn clockwise the orange pin of the timer with a screwdriver, until
the unit goes in defrost.
12. Always charge fresh water before starting ice production, at first installation and after a long
shut-off period.
To start and stop unit, only use the external disconnect multi-pole switch.
2.

INSTALLATION

2.A. CONNECTIONS
LOCAL ELECTRICAL REQUIREMENTS.
2.B. SET-UP
PAG.9
SELF CONTAINED UNITS WITH TIMER
COMPACT SERVICE MANUAL
