4.3 Direct connection of the ISCAN101 handheld scanner without plug connection to
the power supply with RS232 interface - connection with cable end sleeve
Pin assignment
Operating Instructions_iSCAN101_001
RS232 cable
RJ45 pin
Wire
assignme
colours
nt
6 White
7 Brown
3 Yellow
intrinsically safe connection box
of the ISCANPS RS232 power supply
after removal of the wires of the plug connection
Power supply
Connection
Definition terminal power
supply
TXD X9
X10
X11
GND X12
+UB X13
Definition
RXD
GND
PE
GND
+UB
14
