4.2 Step 2 - Connection of ISCANPS power supply

Pin assignment of the plug connector and the pin assignment of the direct connections to the power
supply ISCANPS
Pin assignment
Pin assignment
Operating Instructions_iSCAN101_001
The terminal assignment is located underneath the removable cover at
the front of the power supply.
Before operating the device in a hazardous area you have to ensure
that the enclosure has been closed fully and all screws have been
tightened.
Handheld scanner RS232 cable
Wire number
pin assignment
connection coupling
3
2
1
Handheld scanner USB cable
Wire number
pin assignment
connection coupling
3
2
4
1
Caution: Do not open enclosure in the hazardous
area.
Cables may only be connected by trained staff.
Power supply
Terminals
Definition
Definition
TxD RxD
GND
PE
GND GND
+UB +UB
Power supply
Terminals
Definition
Definition
D+ D+
D- D-
PE
GND GND
+UB +UB
Terminal number
X9
X10
X11
X12
X13
Terminal number
X9
X10
X11
X12
X13
13
