WIRELESS WEATHER STATION
MODEL NO.: 1280/ 1281
1. INTRODUCTION ................................................................................ 2
1.1 PACKAGE CONTENTS ...............................................................................2
1.2 FEATURES ....................................................................................................2
2. INSTALLATION ..................................................................................................2
2.1 INSTALLING THE BATTERIES ...................................................................2
2.2 MOUNTING ...................................................................................................4
2.2.1 BASE STATION......................................................................................4
2.2.2 REMOTE SENSOR ...............................................................................5
3. OVERVIEW .........................................................................................................5
3.1 BASE UNIT-LCD ...........................................................................................5
3.2 LED BACKLIGHT ..........................................................................................6
3.3 WEATHER FORECASTING ........................................................................6
3.4 WEATHER FORECAST TENDENCY INDICATOR ..................................7
3.5
3.6 STORM WARNING INDICATOR ................................................................7
4. PROGRAM MODE .............................................................................................7
4.1 TIME MODE ..................................................................................................8
4.2 INDOOR TEMPERATURE & HUMIDITY MODE .....................................9
4.3 OUTDOOR TEMPERATURE MODE ......................................................10
5. TROUBLESHOOTING ....................................................................................10
6. SPECIFICATION ................................................................................ 11
This Operation Manual is part of this product and should be kept in a
safe place for future reference. It contains important notes on setup and
operation.
*NOTE:This is a combined operation manual for 1280 and 1281. 1280
can receive and display the DCF radio controlled time and date
(RCC function). 1281 maintain all the functions of 1280 but without
RCC function.
INSTRUCTION MANUAL
-1-
Page
.........7
Advertisement
Table of Contents
Related Manuals for Lacrosse WS1281
Summary of Contents for Lacrosse WS1281
-
Page 1: Table Of Contents
WIRELESS WEATHER STATION INSTRUCTION MANUAL MODEL NO.: 1280/ 1281 Page 1. INTRODUCTION ................2 1.1 PACKAGE CONTENTS ................2 1.2 FEATURES ....................2 2. INSTALLATION ....................2 2.1 INSTALLING THE BATTERIES ..............2 2.2 MOUNTING ....................4 2.2.1 BASE STATION..................4 2.2.2 REMOTE SENSOR ................5 3. OVERVIEW ......................5 3.1 BASE UNIT-LCD ...................5 3.2 LED BACKLIGHT ..................6 3.3 WEATHER FORECASTING ................6... -
Page 2: Introduction
1. Introduction Thank you for purchasing this Wireless Weather Station. Designed for everyday use, the weather station will prove to be an asset of great value for your personal use in the home or office. Please read this instruction manual thoroughly to fully understand the correct operation of your weather station and benefit from its unique feature. - Page 3 1) Insert two AAA batteries into the remote sensor. After the remote sensor is powered up, the sensor will transmit weather data every 8s for 16 times. After this learning period is over, then the transmitter will transmit every 48s. 2) Insert two AA batteries into the weather station.
-
Page 4: Mounting
Note: DO NOT PRESS ANY KEY on the base station until the first set of data is display on the LCD. This ensures that the base station has synchronized with the sensors and that the system is now functioning. If a key is pressed before the weather station receives the temperature signal, you will need to follow the battery installation procedure again. -
Page 5: Remote Sensor
2.2.2 Remote Sensor Note: To achieve a true temperature reading, avoid mounting remote sensor in direct sunlight. We recommend that you mount the remote sensor on an outside North-facing wall; obstacles such as walls, concrete, and large metal objects will reduce the range. -
Page 6: Led Backlight
1. Weather tendency arrow 8.Indoor temperature display 2.Weather forecast icon 9.Indoor Humidity display 3.Time alarm icon 10.MIN/MAX icon 4.DCF tower icon for time 11 . Tr a n s m i t t e r l o w b a t t e r y reception indicator 5.Time / Date... -
Page 7: Weather Forecast Tendency Indicator
3.4 Weather tendency indicator The weather tendency indicators arrow is located beside the weather icons to show the air pressure tendency and provide a forecast of the weather to be expected by the decreasing or increasing air pressure. The upward arrow means that the air pressure is increasing and the weather is expected to become better. -
Page 8: Time Mode
4.1 Time Modes - Press the MODE key to make the arrow point to TIME display section - Press the CH/+ key to shift the display of time, calendar(day-month- year) and alarm time - Press the -/MIN/MAX key to on/off the alarm. If alarm is enabledl, will show in the TIME display section indicating the alarm function has been enabled - Press the MODE/SET key for 3s to select the following setting in sequence:... -
Page 9: Indoor Temperature & Humidity Mode
Set alarm time 1. While in normal time display mode, press the CH/+ key twice to display alarm time 2. Press SET/ MODE key for 3s to enter alarm time setting mode. 3. The hour digit will start flashing, press CH/+ key or -/min/max key to set the hour. -
Page 10: Outdoor Temperature Mode
Reset the indoor temperature and humidity MIN/MAX value Press the MIN/MAX key for 3 seconds, the above individual minimum or maximum record will be reset to zero 4.3 Outdoor Temperature Mode Press the MODE key to make the arrow point to OUTDOOR TEMPERATURE display section - Press and release CH/+ key to toggle between the outdoor sensor 1,2,3 ( If more than 1 sensor is used ) -
Page 11: Specification
1.4 This problem could also be a result of radio interference in your neighborhood, try relocating the sensor and the base station Q 2 Remote sensor drops off intermittently A Possible interference from other sources, try relocating the sensor or the base station. Radio device operation on the same frequency can also cause interference. - Page 12 Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
