Lacrosse WS9032 Instruction Manual

WEATHER STATION
Instruction Manual
INTRODUCTION:
Congratulations on purchasing this state-of-the-art weather station as an example of innovative
design and quality piece of engineering. Providing radio controlled time, date, calendar, Moon
phase, indoor and outdoor temperature, indoor and outdoor relative humidity, and air pressure
history information. This unit will never keep you guessing on current and future weather conditions.
Operation of this product is simple and straightforward. By reading this operating manual, the user
will receive a better understanding of the Weather Station together with the optimum benefit of all its
features.
FEATURES:
The Weather Station
LCD Display
Function keys
•
DCF Radio controlled time with manual setting option
•
Time reception ON/OFF (user selectable)
•
12/24 hour time display
•
Time zone option ±12 hours
•
Weekday and day calendar display (year and month only in setting mode)
•
Alarm setting with snooze function
•
Display 12 Moon phases throughout the year
•
Weather forecasting with weather tendency indicator
•
Indoor comfort indicator
•
Temperature display in ºC/ºF
•
Indoor and outdoor temperature display with MIN/MAX records and time of reception
•
Humidity data display as RH%
•
Indoor and outdoor humidity display with MIN/MAX records
•
Relative air pressure hPa/ inHg with adjustable reference value
•
Weather icon sensitivity setting
•
Relative air pressure history for the past
pressure trend)
•
LCD contrast selectable
•
Can receive up to 3 outdoor transmitters
Hanging hole
Battery
compartment
Stand
24 hours (electronic barometer with barometric
•
LED back light
•
Low battery indicator
•
Table standing or wall mounting
Thermo-Hygro Transmitter
•
•
•
TO INSTALL AND REPLACE BATTERIES IN THE WEATHER STATION
The Weather Station uses 3 x AA, IEC LR6, 1.5V batteries. To install
and replace the batteries, please follow the steps below:
1. Insert finger or other solid object in the space at the bottom
center of the battery compartment and lift up to remove the
cover.
2. Insert batteries observing the correct polarity (see marking).
3. Replace compartment cover.
TO INSTALL AND REPLACE BATTERIES IN THE THERMO-HYGRO
TRANSMITTER
The Thermo-Hygro Transmitter uses 2 x AAA, IEC, LR3, 1.5V batteries. To install and replace the
batteries, please follow the steps below:
1.
2.
3.
Note:
In the event of changing batteries in any of the units, all units need to be reset by following the
setting up procedures. This is due to a random security code assigned by the transmitter at start-up.
This code must be received and stored by the Weather Station in the first 3 minutes of power being
supplied to the transmitter.
BATTERY CHANGE:
It is recommended to replace the batteries in all units on an annual basis to ensure optimum
accuracy of these units.
Please participate in the preservation of the environment. Return used batteries to
an authorized depot.
SETTING UP
1. First, insert the batteries into the Weather station (see "How to install and replace batteries
in the Weather station" above). Once the batteries are in place, all segments of the LCD will
light up briefly and a short signal tone will sound.
the time as 0:00 the date as TH.1., the moon icon,
Remote transmission of outdoor temperature and
humidity to weather station by 433 MHz signals
LCD showing outdoor temperature and humidity
Wall mounting case
Unscrew the screw on the back of the compartment and
remove the cover.
Insert the batteries, observing the correct polarity (see
marking).
Replace the battery cover on the unit and seal by re-
screwing.
Then the indoor temperature and humidity,
the weather icons (sun and clouds) will be
