WIRELESS 868 MHz WEATHER STATION
INTRODUCTION
Congratulations on purchasing this weather station as an example of innovative design and quality piece of
engineering. Providing time, date, calendar, moon phase, sunrise/sunset time, indoor and outdoor temperature,
indoor and outdoor relative humidity, and air pressure history information, this unit will never keep you guessing
on current and future weather conditions. Operation of this product is simple and straightforward. By reading this
operating manual, the user will receive a better understanding of the weather station together with the optimum
benefit of all its features.
« Instant Transmission+» is the up and coming state-of-the-art new wireless transmission
technology, exclusively designed and developed by LA CROSSE TECHNOLOGY.
"IT +" offers you an immediate update of all your outdoor data measured from the
transmitters: follow your climatic variations in real-time!
FEATURES
The weather station
LCD
Display
•
24 hour time display (seconds displayed by pressing the SUN key)
•
Weekday, date and month display (year only in setting mode)
•
Daylight saving time (DST) function selectable
•
Daily alarm function
•
Weather forecast with weather tendency indicator
Instruction Manual
20
Function
Keys
Hanging hole
Battery cover
Foldout
stand
Advertisement
Table of Contents
Related Manuals for Lacrosse WS9257IT
Summary of Contents for Lacrosse WS9257IT
- Page 1 WIRELESS 868 MHz WEATHER STATION Instruction Manual INTRODUCTION Congratulations on purchasing this weather station as an example of innovative design and quality piece of engineering. Providing time, date, calendar, moon phase, sunrise/sunset time, indoor and outdoor temperature, indoor and outdoor relative humidity, and air pressure history information, this unit will never keep you guessing on current and future weather conditions.
- Page 2 • Temperature display in degree Celsius (°C) • Indoor temperature display with MIN/MAX recordings • Outdoor temperature display with MIN/MAX recordings, time and date • All MIN/MAX temperature recordings can be reset • Indoor and outdoor relative humidities display in RH% •...
-
Page 3: Battery Change
Insert batteries, observing the correct polarity (see marking). Replace the compartment cover. Note: Always wait for 2 minutes after removing the batteries before reinserting, otherwise start up and transmission problems may occur. In the event of changing batteries in any of the units, all units need to be reset by following the setting up procedures. -
Page 4: Alarm Key
SUN key ALARM key SET key + key MIN/MAX key SET key • Press and hold for 3 seconds to enter manual setting modes: LCD contrast, DST ON/OFF, manual time, calendar and relative air pressure reference value • To stop the alarm sound •... -
Page 5: Manual Settings
Weekday Alarm Time icon Indoor Temperature in ° C Indoor humidity display in RH% Moon phase indicator Calendar Sunrise Time Sunset Time Weather forecast icon Air pressure history bar graph Weather Tendency indicator Air pressure in hPa (relative or absolute) Low battery indicator (Weather Station) Low battery... -
Page 6: Lcd Contrast Setting
LCD CONTRAST SETTING Digit flashing The LCD contrast can be set within 8 levels, from LCD 0 to LCD 7 (Default is LCD 3): The digit starts flashing Press the + key or MIN/MAX key to set the level of contrast desired. Press the SET key to confirm and enter the “Daylight Saving Time On/Off setting,”... - Page 7 The year digits will start flashing. Use the + key to increase or MIN/MAX key to decrease the value. The range runs from 2011 to 2025. Press the SET key to confirm and enter the month setting mode. The month digit will be flashing. Use the + key to increase or MIN/MAX key to decrease the value. Press the SET key to enter date setting, or exit the setting mode by pressing the ALARM key or SUN key.
-
Page 8: Alarm Setting
The City code will start flashing. Use the + key or MIN/MAX key to select the City. Keep holding the key allows the value to advance faster. City Code (flashing) Confirm with the SUN key, or exit the setting mode by pressing the SET key or ALARM key without saving the changes. -
Page 9: Weather Forecasting Icons
TO EXIT SETTING MODE To exit the setting mode anytime without saving the changes, user can wait for automatic timeout to return to normal display. WEATHER FORECASTING ICONS Weather icons can be displayed in any of the following combinations: Cloud with Sun with cloud rain For every sudden or significant change in the air pressure, the weather icons will update accordingly to represent... -
Page 10: Air Pressure History (Electronic Barometer With Barometric Pressure Trend)
Note: Once the weather tendency indicator has registered a change in air pressure, it will remain permanently visualized on the LCD. AIR PRESSURE HISTORY (ELECTRONIC BAROMETER WITH BAROMETRIC PRESSURE TREND) The right side of the second section of the LCD shows the air pressure history bar graph. Air pressure trend over the last 12 hours The bar graph indicates the air pressure history trend over the last 12 hours in 5 intervals: 0h, -3h, -6h, -9h and -... - Page 11 DISPLAY OF INDOOR TEMPERATURE AND HUMIDITY The indoor temperature and humidity data are automatically updated and displayed on the first section of the LCD screen. Indoor temperature Indoor relative humidity in ºC in RH% DISPLAY OF OUTDOOR TEMPERATURE AND HUMIDITY The last LCD section shows the outdoor temperature, MIN/MAX temperature records, humidity and the signal reception indicator.
-
Page 12: Low Battery Indicators
THE MOON PHASE ICONS The weather station displays 8 different moon phase icons. The current moon phase is indicated with a bar segment according to the set calendar. A bar segment indicates the current moon phase Waxing First Waxing Full Waning Last Waning... -
Page 13: Care And Maintenance
Foldout table stand: The foldout table stand leg is located on the backside. Pull the stand out from the bottom center edge of the weather station, below the battery compartment. Once the foldout table stand is extended, place the weather station in an appropriate location. POSITIONING THE THERMO-HYGRO TRANSMITTER: The thermo-hygro transmitter can be placed onto any flat surface or wall mount using the bracket which doubles as a stand or wall mount base. -
Page 14: Specifications
SPECIFICATIONS Temperature measuring range: Indoor -9.9ºC to +59.9ºC with 0.1ºC resolution 14.2ºF to 139.8ºF with 0.2ºF resolution (“OF.L” displayed if outside this range) Outdoor -39.9ºC to +59.9ºC with 0.1ºC resolution -39.8ºF to +139.8ºF with 0.2ºF resolution (“OF.L” displayed if outside this range, “--.-” displayed if no transmitter signal) Relative humidity measuring range: Indoor 20% to 95% with 1% resolution...
