Installation Instructions
27" & 30" Electric Built-in Wall Ovens
Questions?
Call 1,800,GE,CARES (1,800,432,2737) or visit www,GEAppliances,com
In Canada, call 1,800,561,3344 or visit www,GEAppliances,ca
BEFORE YOU BEGIN
Read these instructions completely and
carefully,
" IM PORTANT -- Save theseinstructions
for local inspector's use,
" IMPORTANT -- Observe all governing
(:odes and ordinances,
• Note to Installer - Be sure to leave these
instructions with Consumer,
• Note to Consumer - Keep these instructions
for future reference.
• Skill level - Installation of this appliance
requires a qualified installer or electrician.
• Proper installation is the responsibility
of the installer.
. Product failure due to improper installation
is not covered under Warranty.
. Product is for indoor use only.
ATTENTION INSTALLER:
Aii electric wall ovens must be hard-wired (direcbwired)into an
approved junction box. A plug and receptacle is NOT permitted on these products.
FOR YOUR SAFETY:
AWARNING:
Before begirrnirrg the ,rrstallation, switch power off at the service panel and
lock the service disconnecting means to prevent power from being switched on accidentally. When the
service disconnecting means cannot be locked, securely fasten a prominent warning device, such as a tag,
to the service panel.
Be sure the oven is securely irrstalled in a cabinet that is firmly attached to the house structure.
Weight orr the oven door could cause the oven to tip arrd result in injury. Never allow anyone to climb, sit,
stand or hang orr the oven door.
Make sure the wall coverings, counters and cabinets around the oven can withstand the Preat
(up to 200°F [93.3°C]) generated by the oven.
MATERIALS YOU MAY NEED
Junction Box
Wire Nuts
Strain Relief Clamp for 1/2" Conduit
TOOLS YOU MAY NEED
1/8" Drill Bit arrd Electric or Hand Drill
T20 Screwdriver
Phillips Screwdriver
Wire Strippers
DESIGN INFORMATION
SINGLE OVEN INSTALLATIONS
The single oven may be installed in a cabinet alorre or above a warming drawer. The single oven may also
be irrstalled below a countertop or below specified cooktops. See the label on top of the oven for approved
models.
DOUBLE OVEN INSTALLATIONS
A double oven may be irrstalled in a cabinet alone or above a warmirrg drawer. See the label on top of the
oven for approved models.
IMPORTANT: Always refer to individual installation irrstructions packed with each product for specific
requirements.
[_] PREPARE THE OPENING
NOTE: If the cabinet does not have a solid bottom, two
braces or runners must be installed to support the weight
of the oven. For single ovens, the runners and braces
must support 200 Ibs (91 kg). For double ovens, the
runners and braces must support 375 Ibs. (170 kg).
NOTE: If marks, blemishes or the cutout opening are
visible above the installed oven, it may be necessary to
add wood shims under the runners and front trim until
the marks or opening are covered.
NOTE: If the cabinet does not have a front frame and
the sides are less than 3/4"(1.9 cm) thick, shim both sides
equally to establish the cutout width.
2" x 4"{5 cm x 10 cm)
or Equivalent Runners Level
with Bottom of Cutout
and Flush with Sides of Cutout
Suitable
Bracing
to Support.
REMOVE PACKAGING MATERIALS
Failure to remove packaging materials could result in damage to the appliance. Remove all packing
parts from oven, racks and heating elements. Remove protective film and labels on the outer door
and control panel. Also, remove plastic on trims and panel, all tape around the oven and any shipping
screws securing the oven to the base pad. Open oven door and remove literature pack and oven
racks. Remove the bottom trim from the top of the oven. It will be installed at the end of the installation
process. The trim is wrapped separately and taped to the top of the unit. Remove pedestal rails from
seperate box and set aside (30" Double Wall Ovens Only).
